AC Line / Load Reactors
User Manual
Data subject to change without notice 11 of 32 INSTR-011 REL. 150109 REV.006
See www.mtecorp.com for current data and CAD drawings
PRODUCT SPECIFICATIONS (cont’d)
AGENCY APPROVALS:
UL-508, File E180243 Component Listed (1 amp – 2400 amps)
UL-508, File E180243 UL Listed NEMA 1 units (1 amp – 2400 amps)
CSA C22.2, File LR29753-13 CSA Certified (1 amp – 2400 amps)
Class N, 200° C, File E66214, Type 200-18, UL Recognized Insulation System
CE Marked
MATERIAL:
Core Steel: Electrical grade silicon steel
Windings: High dielectric withstand solid copper conductor (220° C)
Enclosures: Sheet steel in accordance with UL and CSA requirements. Painted ANSI-61
Grey
Brackets: ASTM structural steel or structural aluminum
Terminations: 1 – 45 amps - Finger safe terminal block
55 - 160 amps - Solid copper box lugs (Tab terminals are optional)
200 + amps - Copper tab terminals
Sheet Insulation: DuPont Nomex 410 (220° C)
Epoxy: Ripley Resin Type 468-2 (220° C)
CONSTRUCTION:
CORE: Electrical grade silicon steel magnetic laminations.
WINDINGS: Meet 3000 volts rms dielectric strength (coil – to coil and coil- to – core).
ASSEMBLY: Windings are assembled onto EI laminations, secured in place and epoxy
impregnated for minimum noise and maximum structural rigidity.
COLOR: Royal Blue
TESTING: Electronic Turns Count (Zero Tolerance)
Inductance
Hi-Pot 3000 Volts rms (5656 volts peak)
Mechanical Inspection
