MTE RL Series - Technical Data (Part 1); Technical Specifications Table (Watts Loss, Wire Range, Torque, Inductance, Fund;Max Amps)

AC Line / Load Reactors
User Manual
Data subject to change without notice 25 of 32 INSTR-011 REL. 150109 REV.006
See www.mtecorp.com for current data and CAD drawings
TECHNICAL DATA
Catalog
Watts Loss
Wire Range
Terminal Torque
Ind.
Fund
Max
Number
(watts)
(AWG)
(in – lbs)
mH
Amps
Amps
RL-00101
13.5
22 – 10
4.5
100
1
1.5
RL-00102
12.8
22 – 10
4.5
50
1
1.5
RL-00103
11.9
22 – 10
4.5
36
1
1.5
RL-00104
9.6
22 – 10
4.5
18
1
1.5
RL-00201
8
22 – 10
4.5
12
2
3
RL-00202
12
22 – 10
4.5
20
2
3
RL-00203
16
22 – 10
4.5
32
2
3
RL-00204
11
22 – 10
4.5
6
2
3
RL-00401
15
22 – 10
4.5
3
4
6
RL-00402
20
22 – 10
4.5
6.5
4
6
RL-00403
20
22 – 10
4.5
9
4
6
RL-00404
21
22 – 10
4.5
12
4
6
RL-00801
20
22 – 10
4.5
1.5
8
12
RL-00802
29
22 – 10
4.5
3
8
12
RL-00803
26
22 – 10
4.5
5
8
12
RL-00804
28
22 – 10
4.5
7.5
8
12
RL-01201
26
14 - 6
16
1.25
12
18
RL-01202
31
14 - 6
16
2.5
12
18
RL-01203
41
14 - 6
16
4.2
12
18
RL-01801
36
14 - 6
16
0.8
18
27
RL-01802
43
14 - 6
16
1.5
18
27
RL-01803
43
14 - 6
16
2.5
18
27
RL-02501
48
14 - 6
16
0.5
25
37.5
RL-02502
52
14 - 6
16
1.2
25
37.5
RL-02503
61
14 - 6
16
1.8
25
37.5
RL-03501
49
14 - 6
16
0.4
35
52.5
RL-03502
54
14 - 6
16
0.8
35
52.5
RL-03503
54
18 – 4
16
1.2
35
52.5
RL-04501
54
18 – 4
16
0.3
45
67.5
RL-04502
62
18 – 4
16
0.7
45
67.5
RL-04503
65
18 – 4
16
1.2
45
67.5
RL-05501
64
6 – 0
6-4(45) & 2-0(50)
0.25
55
82.5
RL-05502
67
6 – 0
6-4(45) & 2-0(50)
0.5
55
82.5
RL-05503
71
6 – 0
6-4(45) & 2-0(50)
0.85
55
82.5
RL-08001
82
6 – 0
6-4(45) & 2-0(50)
0.2
80
120
RL-08002
86
6 – 0
6-4(45) & 2-0(50)
0.4
80
120
RL-08003
96
6 – 0
6-4(45) & 2-0(50)
0.7
80
120
RL-10001
94
6 – 0
6-4(45) & 2-0(50)
0.15
100
150
RL-10002
84
6 – 0
6-4(45) & 2-0(50)
0.3
100
150
RL-10003
108
6 – 0
6-4(45) & 2-0(50)
0.45
100
150
RL-13001
108
2 – 0000
150
0.1
130
195
RL-13002
180
2 – 0000
150
0.2
130
195
RL-13003
128
2 – 0000
150
0.3
130
195
RL-16001
116
2 – 0000
150
0.075
160
240
