MTE RL Series - Mechanical Details for Open Reactors

AC Line / Load Reactors
User Manual
Data subject to change without notice 16 of 32 INSTR-011 REL. 150109 REV.006
See www.mtecorp.com for current data and CAD drawings
Mechanical Details Open Reactors
MTE Weight Mass
Cat. No. Inches mm Inches mm Inches mm Inches mm Inches mm Lbs Kg
RL-00101 3.8 97 3.5 89 1.2 30 2.40 61.0 1.44 36.6 4 1.8
RL-00102 3.8 97 3.5 89 1.2 30 1.98 50.3 1.44 36.6 4 1.8
RL-00103 3.8 97 3.5 89 1.2 30 1.98 50.3 1.44 36.6 3 1.4
RL-00104 3.8 97 3.5 89 1.2 30 1.98 50.3 1.44 36.6 3 1.4
RL-00201 4.4 112 4.1 104 2.8 71 1.98 50.3 1.44 36.6 4 1.8
RL-00202 4.4 112 4.1 104 2.8 71 1.98 50.3 1.44 36.6 4 1.8
RL-00203 4.4 112 4.1 104 2.8 71 1.98 50.3 1.44 36.6 4 1.8
RL-00204 4.4 112 4.1 104 2.5 64 1.73 43.9 1.44 36.6 3 1.4
RL-00401 4.4 112 4.1 104 2.8 71 1.98 50.3 1.44 36.6 4 1.8
RL-00402 4.4 112 4.1 104 2.8 71 1.98 50.3 1.44 36.6 4 1.8
RL-00403 4.4 112 4.1 104 3.4 86 2.35 59.7 1.44 36.6 5 2.3
RL-00404 4.4 112 4.1 104 3.4 86 2.60 66.0 1.44 36.6 6 2.7
RL-00801 6.0 152 4.8 122 3.0 76 2.10 53.3 2.00 50.8 7 3.2
RL-00802 6.0 152 4.8 122 3.0 76 2.10 53.3 2.00 50.8 8 3.6
RL-00803 6.0 152 4.8 122 3.4 86 2.62 66.5 2.00 50.8 11 5.0
RL-00804 6.0 152 4.8 122 3.4 86 2.48 63.0 2.00 50.8 13 5.9
RL-01201 6.0 152 5.0 127 3.3 84 2.10 53.3 2.00 50.8 9 4.1
RL-01202 6.0 152 5.0 127 3.3 84 2.10 53.3 2.00 50.8 10 4.5
RL-01203 6.0 152 5.0 127 3.9 99 2.75 69.9 2.00 50.8 18 8.2
RL-01801 6.0 152 5.3 135 3.2 81 2.10 53.3 2.00 50.8 9 4.1
RL-01802 6.0 152 5.3 135 3.5 89 2.48 63.0 2.00 50.8 12 5.4
RL-01803 8.1 206 6.1 155 4.0 102 2.60 66.0 3.00 76.2 16 7.3
RL-02501 7.2 183 5.8 147 3.5 89 2.35 59.7 3.00 76.2 11 5.0
RL-02502 7.2 183 5.8 147 3.5 89 2.35 59.7 3.00 76.2 14 6.3
RL-02503 7.2 183 5.8 147 4.3 109 3.10 78.7 3.00 76.2 20 9.1
RL-03501 7.2 183 5.8 147 4.0 102 2.60 66.0 3.00 76.2 14 6.3
RL-03502 7.2 183 5.8 147 4.0 102 2.75 69.9 3.00 76.2 16 7.3
RL-03503 9.0 229 7.4 188 4.7 119 3.16 80.3 3.00 76.2 30 14
RL-04501 9.0 229 7.4 188 4.7 119 3.16 80.3 3.00 76.2 23 10
RL-04502 9.0 229 7.4 188 4.7 119 3.16 80.3 3.00 76.2 28 13
RL-04503 9.0 229 7.3 185 5.3 135 3.66 93.0 3.00 76.2 39 18
RL-05501 9.0 229 7.3 185 5.3 135 3.16 80.3 3.00 76.2 24 11
RL-05502 9.0 229 7.0 178 5.3 135 3.16 80.3 3.00 76.2 27 12
RL-05503 9.0 229 7.0 178 6.0 152 3.91 99.3 3.00 76.2 41 19
RL-08001 9.0 229 7.2 183 6.3 160 3.47 88.1 3.63 92.2 25 11
RL-08002 9.0 229 7.2 183 6.5 165 3.47 88.1 3.63 92.2 33 15
RL-08003 10.8 274 8.5 216 6.8 173 4.16 105.7 3.63 92.2 61 28
RL-10001 9.0 229 7.3 185 6.5 165 3.30 83.8 3.63 92.2 29 13
RL-10002 9.0 229 7.3 185 6.8 173 3.66 93.0 3.63 92.2 37 17
RL-10003 10.8 274 8.3 210 6.2 156 4.16 105.7 3.63 92.2 74 34
RL-13001 9.0 229 7.0 178 4.7 118 3.16 80.3 3.00 76.2 29 13
RL-13002 9.0 229 7.2 183 6.8 173 3.66 93.0 3.63 92.2 43 20
RL-13003 11.0 279 8.5 216 6.2 156 4.16 105.7 3.63 92.2 64 29
RL-16001 9.0 229 7.2 183 6.8 173 3.16 80.3 3.63 92.2 41 19
RL-16002 10.8 274 8.3 211 6.0 152 3.47 88.1 3.63 92.2 50 23
E
A
B
C
D
See www.mtecorp.com “Line load Reactors” for current dimensions and CAD details
