MTE RL Series - Mechanical Details for Open Reactors (Continued)

AC Line / Load Reactors
User Manual
Data subject to change without notice 17 of 32 INSTR-011 REL. 150109 REV.006
See www.mtecorp.com for current data and CAD drawings
Mechanical Data Open Type Cont.
MTE Weight Mass
Cat. No. Inches mm Inches mm Inches mm Inches mm Inches mm Lbs Kg
RL-20001B14 9.0 229 7.5 191 7.3 185 4.16 105.7 3.63 92.2 38 17
RL-20002B14 9.0 229 7.5 191 8.3 211 4.41 112.0 3.63 92.2 54 24
RL-20003B14 10.8 274 8.3 211 10.0 254 5.91 150.1 3.63 92.2 100 45
RL-25001B14 9.0 229 7.5 191 9.0 229 4.19 106.4 3.63 92.2 47 21
RL-25002B14 10.8 274 8.5 216 9.0 229 5.16 131.1 4.60 116.8 80 36
RL-25003B14 14.4 366 11.2 284 10.3 262 5.82 147.8 4.60 116.8 125 57
RL-32001B14 10.8 274 9.0 229 8.3 211 5.16 131.1 4.60 116.8 80 36
RL-32002B14 10.8 274 9.0 229 10.0 254 5.88 149.4 4.60 116.8 102 46
RL-32003B14 14.4 366 11.3 286 10.5 267 7.13 181.1 4.60 116.8 160 73
RL-40001B14 10.8 274 10.0 254 10.0 254 5.16 131.1 4.60 116.8 84 38
RL-40002B14 15.0 381 11.3 286 11.5 292 6.76 171.7 4.60 116.8 118 54
RL-40003B14 14.4 366 11.3 286 12.5 318 7.26 184.4 4.60 116.8 149 68
RL-50001 10.8 274 9.0 229 10.5 267 5.50 139.7 4.60 116.8 93 42
RL-50002 14.4 366 11.5 292 11.5 292 6.76 171.7 4.60 116.8 118 54
RL-50003 14.4 366 11.5 292 13.3 338 9.76 247.9 4.60 116.8 210 95
RL-60001 14.4 366 11.5 292 10.0 254 5.26 133.6 4.60 116.8 120 54
RL-60002 14.4 366 11.3 286 12.0 305 8.00 203.2 4.60 116.8 175 79
RL-60003 14.4 366 11.3 286 15.0 381 9.26 235.2 4.60 116.8 270 122
RL-75001 14.4 366 11.5 292 11.0 279 6.63 168.4 7.20 182.9 140 63
RL-75002 14.4 366 11.5 292 12.5 318 8.01 203.5 7.20 182.9 190 86
RL-75003 14.4 366 14.5 368 14.0 356 9.26 235.2 7.20 182.9 265 120
RL-85001 20.3 514 16.8 425 13.0 330 7.60 193.0 7.20 182.9 285 129
RL-85002 22.0 559 16.8 425 13.0 330 8.00 203.2 7.20 182.9 370 168
RL-85003 22.5 572 16.8 427 18.0 457 9.00 228.6 7.20 182.9 452 205
RL-100001 21.6 549 16.8 425 11.0 279 7.26 184.4 7.20 182.9 320 145
RL-100002 20.3 514 16.8 425 13.0 330 8.50 215.9 7.20 182.9 408 185
RL-100003 20.3 514 16.8 425 15.0 381 10.76 273.3 7.20 182.9 589 267
RL-120001 22.5 572 17.0 432 13.0 330 11.00 279.4 7.20 182.9 425 193
RL-120002 21.5 546 17.0 432 20.0 508 10.76 273.3 7.20 182.9 440 200
RL-120003 16.8 427 17.0 432 18.5 470 11.00 279.4 7.20 182.9 560 254
RL-140001 22.0 559 17.0 432 22.0 559 11.00 279.4 7.20 182.9 500 227
RL-140002 19.0 483 17.0 432 19.0 483 11.00 279.4 7.20 182.9 525 238
RL-140003 22.0 559 17.0 432 22.0 559 11.00 279.4 7.20 182.9 850 385
RL-150001 22.0 559 17.0 432 22.0 559 11.00 279.4 7.20 182.9 635 288
RL-150002 16.9 429 17.0 432 16.0 406 11.00 279.4 7.20 182.9 675 306
RL-150003 22.0 559 17.0 432 22.0 559 11.00 279.4 7.20 182.9 900 408
RL-180001 22.0 559 17.0 432 22.0 559 11.00 279.4 7.20 182.9 700 317
RL-180002 22.0 559 17.0 432 22.0 559 10.38 263.7 7.20 182.9 860 390
RL-180003 22.0 559 17.0 432 22.0 559 11.00 279.4 7.20 182.9 1090 494
RL-210001 24.0 610 18.0 457 24.0 610 11.00 279.4 7.20 182.9 800 363
RL-210002 24.0 610 18.0 457 24.0 610 11.00 279.4 7.20 182.9 970 440
E
A
B
C
D
See www.mtecorp.com “Line load Reactors” for current dimensions and CAD details
