Sine Wave 2-8 kHz Series A Filter
32 Part No. INSTR-020 REL. 080310
Maximum RC PANEL Current for Open Wiring
Inter-connect wire sizes
Table 8
Filter
Rating
230 Vac Units 460 Vac Units 575 Vac units
Amps Maximum Amps RMS Maximum Amps RMS Maximum Amps RMS
80 10 11 11
110 14 16 16
130 17 17 17
160 21 22 21
200 - 27 23
250 32 33 29
305 - 40 37
320 41 - -
365 47 49 46
415 54 54
515 66 66
600 80 75
720 86 80
See figure 16 for interconnection details. Each of the six interconnection wires
should be rated for the current from the above RC panel wiring table. See table 7
for 75 °C wire examples.
