MTHTrains ES44AC - Recommended Transformers; AC and DC Power Supply Charts

DC Power Supply Chart
Transformer
Model
Min/Max.
Voltage
Power
Rating
Transformer
Type
MRC
Controlmaster 20
0-20v
100-Watt
Electronic
PH Hobbies
PS5
PH Hobbies
PS10G
0-20v
0-20v
100-Watt
180-Watt
Electronic
Electronic
Bridgeworks
Magnum 15
Bridgeworks
Magnum 200
Bridgeworks
Magnum 1000
Bridgeworks
Magnum 400
0-24v *
0-24v *
0-24v *
0-24v *
300-Watt
300-Watt
300-Watt
300-Watt
Electronic
Electronic
Electronic
Electronic
LGB Jumbo
#50101
18VDC on
Supply, 0-18VDC
at Controller
240-Watt
Electronic
MRC 6200
0-18.5v
60-Watt
Electronic
Not Recommended For #70-3001-1 J3a
Not recommended for #70-3001-1 J3a
RECOMMENDED DC TRANSFORMERS
Notes On Use
* Use 22 volts maximum track voltage when operating a MTH locomotive equipped with
Proto-Sound, Loco-Sound, Proto-Sound 2.0, or Proto-Sound 3.0
Crest CRE-55460
Power Supply w/
CRE-55401 Controller
0-24v *
180-Watt
Controller has PWM Output
from Fixed DC Input
Electronic
FOR ANALOG DC OPERATION ONLY
DO NOT Use with the DCS System (TIU)
PWM Output from this power supply
Will DAMAGE the TIU
Transformer
Model
Center Rail Outside Rail
Min/Max.
Voltage
Power
Rating
Transformer
Type
Marklin 6646
(Or Equivalent)
Red Terminal Black Terminal 0-17v 32-VA Standard
RECOMMENDED AC TRANSFORMERS
AC Power Supply Chart
M.T.H. HO ES44AC PS3E+ Diesel Engine
43
Recommended Transformers
