MTS Sensors Temposonics E-Series User Manual

Temposonics
®
E-Series CANopen
Operation Manual
19
Cable connector Connection accessories
~53
(~ 2.09)
Ø 20
(Ø 0.79)
38
(1.5)
20
(0.79)
~ 57
(~2.25)
45
(1.77)
56
(2.2)
48.4
(1.91)
Ø 14.5
(Ø 0.57)
Female, straight, 5 pin
Part no. 370677
Female, angled, 5 pin
Part no. 370678
CANopen T-Connector, M12, 5 pin
Part no. 370691
CANopen bus terminator
Part no. 370700
Housing: GD-Zn, Ni / IP67
Termination: Screw; max. 0.75 mm²
Contact insert: CuZn
Cable Ø: 4…8 mm
Fastening torque: Max. 0.6 Nm
Housing: GD-Zn, Ni / IP67
Termination: Screw; max. 0.75 mm
2
Contact insert: CuZn
Cable Ø: 5…8 mm
Fastening torque: Max. 0.6 Nm
Selfcuring coupling nut
2 × cable connector female
1 × cable connector male shielded
Housing: PUR
Contact insert: Au
