MTS Sensors Temposonics E-Series User Manual

Temposonics
®
E-Series CANopen
Operation Manual
8
3.3 Order structure of E-Series EH
Temposonics
®
order code
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
E H
1
C
1
a b c d e
f
g h i
j
optional
a Sensor model
E H
Rod
b Design
Model EH rod-style sensor with housing 1.4305 (AISI 303)
rod, material 1.4301 (AISI 304)
K
Flange M18×1.5-6g / rod Ø 7 mm
L Flange ¾"-UNF-3A / rod Ø 7 mm
Model EH rod-style sensor with housing 1.4305 (AISI 303)
rod, material 1.4306 (AISI 304L)
M Flange M18×1.5-6g / rod Ø 10 mm
S
Flange ¾"-UNF-3A / rod Ø 10 mm
Model EH rod-style sensor with housing 1.4404 (AISI 316L)
rod, material 1.4404 (AISI 316L)
F Flange ¾"-UNF-3A / rod Ø 10 mm
W Flange M18×1.5-6g / rod Ø 10 mm
f Output
C 3
0
4
CANopen
C
4
0
4
CANopen (duo terminator)
e Operating voltage
1
+24 VDC (−15 / +20 %)
g Baud rate
1
1000 kBit/s
2
500 kBit/s
3
250 kBit/s
4
125 kBit/s
d Connection type
D 3 4
5 pin M12
E H 1
2 m PUR cable (Part no. 530 166)
E H 2
5 m PUR cable (Part no. 530 166)
E H 3
10 m PUR cable (Part no. 530 166)
E H 4
15 m PUR cable (Part no. 530 166)
E T 1
2 m Teflon
®
cable (Part no. 530 157)
E T 2
5 m Teflon
®
cable (Part no. 530 157)
E T 3
10 m Teflon
®
cable (Part no. 530 157)
E T 4
15 m Teflon
®
cable (Part no. 530 157)
c Stroke length
X X X X M
0050…2540 mm
X X X X
U
002.0…100.0 in.
Standard stroke length (mm)*
Stroke length Ordering steps
50 … 500 mm 5 mm
500 … 750 mm 10 mm
750…1000 mm 25 mm
1000…2540 mm 50 mm
Standard stroke length (in.)*
Stroke length Ordering steps
2… 20 in. 0.2 in.
20… 30 in. 0.4 in.
30… 40 in. 1.0 in.
40…100 in. 2.0 in.
Optional:
j Magnet number for multi position measurement
Z
0 2
2 magnets
i Type
1
Standard
h Resolution
4
10 µm
5
20 µm
*/ Non standard stroke lengths are available; must be encoded in 5 mm / 0.1 in. increments
.
