MTS Sensors Temposonics E-Series User Manual

Temposonics
®
E-Series CANopen
Operation Manual
41
8. Technical data
7/ Only sensors with connector outlets are UL/cUL certified
Electrical connection
Connection type 5 pin connector M12 or cable outlet (EH only)
Cable EHx (530166) ETx (530157)
Dimension 3 × 2 × 0.14 mm² 3 × 2 × 0.14 mm²
Cable Ø 6.2 mm (0.24 in.) 6.7 mm (0.26 in.)
Material PUR, silver-grey FEP, black
Operating temperature −40…+80 °C (−40…+176 °F) −100…+180 °C (−148…+356 °F)
Characteristics Oil resistant, energy chain, halogen free
Operating voltage +24 VDC (−15 / +20 %); UL Recognition requires an approved power supply with energy
limitation (UL 61010-1), or Class 2 rating according to the National Electrical Code (USA) /
Canadian Electrical Code.
6
Ripple ≤ 0.28 V
PP
Current consumption
40…60 mA depending on stroke length
Dielectric strength 500 VDC (DC ground to machine ground)
Polarity protection Up to −30 VDC
Overvoltage protection Up to 36 VDC
