MTS Systems 318 Series User Manual

318 Load Unit Operation
61
Crosshead Lift/Lock
Controls
Controls the movement and clamping of the crosshead. The left handle raises
and lowers the crosshead. The right handle locks and unlocks the crosshead.
The crosshead must not be moved while it is clamped.
Emergency Stop
Shuts down the hydraulic pressure and stops the test program. Press this button
to shut down hydraulic power, and twist the switch clockwise to release it. Use
the Emergency Stop button to shut down your test if something unexpected
should happen.
Series 318 Load Unit Controls
C
ONTROL DESCRIPTION
Up
Stop
Down
Unlock Lock
