Installation
MTS Landmark™ Tabletop Load Units - Product Information 61
Item Description
1 136 N·m (100 lbf·ft)
2 271 N·m (200 lbf·ft)
3 271 N·m (200 lbf·ft)
Loosen the Manual
Crosshead Locking Bolts
Item Description
1 190 N·m (140 lbf·ft)
Loosen the Manual
Crosshead Locking Bolts
3. Cycle the lock control to unclamp, and then reclamp, the crosshead.
4. Use the lock control to unclamp the crosshead. Wait 30 seconds for the pressure in the
crosshead locks to drop to zero.
5. Use the lift control to position the crosshead where you want it.
6. Use the lock control to clamp the crosshead to its current position. Wait 30 seconds for the
locks to fully clamp the columns.
