8.6.2 Injector – Removal and installation
Preconditions
Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Barring tool
F6557929 1
Puller
3555890163/00 1
Fuel suction device
F30378207 1
Torque wrench, 20–100 Nm
F30026582 1
Ratchet adapter
F30027340 1
Adapter
F30006234 1
Open-end socket wrench, 19 mm
F30025897 1
Crowfoot wrench, 19 mm
F30027424 1
Crowfoot box wrench, 22 mm
F30027425 1
Double-head box wrench
F30011450 1
Assembly compound (Kluthe Hakuform 30-15)
X00067260 1
Engine oil
Sealing ring
(→ Spare Parts Catalog)
Sealing ring
(→ Spare Parts Catalog)
Sealing
(→ Spare Parts Catalog)
WARNING
Fuels are combustible and explosive.
Risk of fire and explosion!
Avoid open flames, electrical sparks and ignition sources.
Do not smoke.
Wear protective clothing, protective gloves, and safety glasses / facial protection.
WARNING
Compressed air gun ejects a jet of pressurized air.
Risk of injury to eyes and damage to hearing, risk of rupturing internal organs!
Never direct air jet at people.
Always wear safety goggles/face mask and ear defenders.
Preparatory steps
1. Close fuel supply line before fuel filter.
2. Drain fuel (→ Page 97).
3. Remove engine governor as necessary (→ Page 142).
4. Remove charge-air manifolds and take off seals (only on engines with air-to-air charge-air cooling).
5. Remove cylinder head cover (→ Page 83).
MS15018/03E 2016-02
