325 – AL Wiring Cylinder A5
Yellow alarm; warning
Cause Corrective action
Short circuit in cylinder A5
injector wiring. Result: Misfiring.
1. Check injector wiring.
2. Rectify injector solenoid valve short circuit (positive to negative)
(e.g. by exchanging injectors).
3. Fault is rectified when engine is restarted.
326 – AL Wiring Cylinder A6
Yellow alarm; warning
Cause Corrective action
Short circuit in cylinder A6
injector wiring. Result: Misfiring.
1. Check injector wiring.
2. Rectify injector solenoid valve short circuit (positive to negative)
(e.g. by exchanging injectors).
3. Fault is rectified when engine is restarted.
327 – AL Wiring Cylinder A7
Yellow alarm; warning
Cause Corrective action
Short circuit in cylinder A7
injector wiring. Result: Misfiring.
1. Check injector wiring.
2. Rectify injector solenoid valve short circuit (positive to negative)
(e.g. by exchanging injectors).
3. Fault is rectified when engine is restarted.
328 – AL Wiring Cylinder A8
Yellow alarm; warning
Cause Corrective action
Short circuit in cylinder A8
injector wiring. Result: Misfiring.
1. Check injector wiring.
2. Rectify injector solenoid valve short circuit (positive to negative)
(e.g. by exchanging injectors).
3. Fault is rectified when engine is restarted.
329 – AL Wiring Cylinder A9
Yellow alarm; warning
Cause Corrective action
Short circuit in cylinder A9
injector wiring. Result: Misfiring.
1. Check injector wiring.
2. Rectify injector solenoid valve short circuit (positive to negative)
(e.g. by exchanging injectors).
3. Fault is rectified when engine is restarted.
