Fault
code no. Full designation Meaning Action
Setting parame-
ter no.
270 SD Frequency Input SD alarm configuration, fre-
quency input faulty, short cir-
cuit or wiring damage.
Contact Service. 2.8006.590
301 AL Timing Cylinder A1 Time-of-flight measuring fault
injector cylinder A1: Time-of-
flight value measured ex-
tremely small or large (alarm
configuration parameter, see
PR 2.8008.100 for explana-
tion).
Replace plug-in
pump if this occurs
frequently.
1.8004.500
302 AL Timing Cylinder A2 Time-of-flight measuring fault
injector cylinder A2 Time-of-
flight value measured ex-
tremely small or large (alarm
configuration parameter, see
PR 2.8008.100 for explana-
tion).
Replace plug-in
pump if this occurs
frequently.
1.8004.501
303 AL Timing Cylinder A3 Time-of-flight measuring fault
injector cylinder A3: Time-of-
flight value measured ex-
tremely small or large (alarm
configuration parameter, see
PR 2.8008.100 for explana-
tion).
Replace plug-in
pump if this occurs
frequently.
1.8004.502
304 AL Timing Cylinder A4 Time-of-flight measuring fault
injector cylinder A4 Time-of-
flight value measured ex-
tremely small or large (alarm
configuration parameter, see
PR 2.8008.100 for explana-
tion).
Replace plug-in
pump if this occurs
frequently.
1.8004.503
305 AL Timing Cylinder A5 Time-of-flight measuring fault
injector cylinder A5 Time-of-
flight value measured ex-
tremely small or large (alarm
configuration parameter, see
PR 2.8008.100 for explana-
tion).
Replace plug-in
pump if this occurs
frequently.
1.8004.504
306 AL Timing Cylinder A6 Time-of-flight measuring fault
injector cylinder A6 Time-of-
flight value measured ex-
tremely small or large (alarm
configuration parameter, see
PR 2.8008.100 for explana-
tion).
Replace plug-in
pump if this occurs
frequently.
1.8004.505
307 AL Timing Cylinder A7 Time-of-flight measuring fault
injector cylinder A7 Time-of-
flight value measured ex-
tremely small or large (alarm
configuration parameter, see
PR 2.8008.100 for explana-
tion).
Replace plug-in
pump if this occurs
frequently.
1.8004.506
MS15018/03E 2016-02 | Troubleshooting | 53
TIM-ID: 0000008508 - 003
