Synchronized splitter (reducing gear)
Type: mechanical, synchronized, with
direct drive and retarding gear. Located
between the clutch and gearbox and
controlled by the lever under the steer-
ing column. Allows reducing speed at
each gear 1.32 times and obtaining 14
forward gears and 4 reverse gears.
Synchronized multiplier
Type: mechanical, synchronized, with
direct drive and multiplying gear. Locat-
ed between the clutch and gearbox and
allows increasing speed at each gear
1.32 times.
Reverse gear (optional)
Type: mechanical, synchronized, with
forward motion and reverse (i=-1.07 or
i=-1.88). Installed instead of step-down
reducing gear and allows obtaining 9
forward gears and 8 reverse ones.
Speed-reducing unit (optional)
Type: mechanical, two-range, two-
speed. It allows super low speeds to be
obtained. Installed instead of left cover
of the gearbox and allows obtaining ad-
ditionally 16 forward gears and 16 re-
verse ones.
