3. To display correctly the PTO’s rotational speeds (540 and 1000), it is necessary to
program the gear ratio PTO “КV2” and the number of teeth of the pinion at the place of
installation of the PTO sensor “ZV” in the specified order:
Select from the Table
- in the absence of the PTO rotational speed sensor (the signal from the phase winding of
the alternator serves as a signal for indication of the PTO rotational speed) the value of
the parameter “ZV” to be entered shall be equal to 0.
- in the absence of the PTO rotational speed sensor (the signal from the phase winding of
the alternator serves as a signal for indication of the PTO rotational speed) the value of
the parameter “ZV” to be entered shall be equal to 0.
4. To display correctly the residue of fuel in the tank (if the FFRS sensor is installed), it is
necessary to program the fuel tank volume “V” in the specified order:
For tractors with plastic fuel tank, set the value of 140 litres.
Also, when pressing the “Parameter” (Параметр) button in the programming mode, the
list of programmable parameters displays the independent parameter of the adjusted
content of the counter of the astronomic time of running the engine. This parameter is
unavailable for measurement; it presents the precise (to 1/10 hours) value of the number
of hours of the engine running.
On switching on the backlight of the instrument scales (the main light switch (MLS)
is set to the positions II “The backlight of the instrument dash and clearance lights are
ON” and III “The consumers of the position II and front road headlights and clearance
lights are ON”), the brightness of the PTO indicator segments and LCD is automatically
reduced.
