2. ТСУ-ЗВ (fork)
Machines: trailed (automobile-type two-axle trailers, etc), semi-trailed (same as for ТСУ-
1Ж-01).
Rotating fork with vertical displacement
Distance from the fork to support-
ing surface for machines without
PTO drive, mm
288.. .808 (962*) stepwise via 65 mm
Fork position for machines with
PTO drive
lowermost or uppermost, including overturn
Distance from PTO face to at-
tachment pin axle, mm
Machine turning angle relative to
the tractor
± 55 (trailers),
± 85 (agricultural machines)
* With turning over the fork
