Set the Offset / Low Level
Press the F3 or F4 key to switch to the Offset/Low Level parameter,
and then use the
direction keys to set the desired value in the
parameter column. Press F2 to switch between Offset / Low Level.
Output the square waveform
Press the F1 key to enter the square waveform setting interface.
The square waveform setting menu includes: Frequency/Period, Start Phase,
Amplitude/High Level, Offset/Low Level.
For the setting frequency/period, amplitude/high level, offset/low level, please
refer to Output the sine waveform on page 26.
Output the ramp waveform
Press the F1 key to enter the ramp waveform setting interface.
The ramp waveform setting menu includes: Frequency/Period, Start Phase,
Amplitude/High Level, Offset/Low Level, Symmetry.
For the setting frequency/period, amplitude/high level, offset/low level, please
refer to Output the sine waveform on page 26.
Set the symmetry of the ramp waveform
Press the F3 or F4 key to switch to the Symmetry parameter, use the
direction keys to set the desired value in the parameter column.
Output the pulse waveform
Press the F1 key to enter the pulse waveform setting interface.
The pulse waveform setting menu includes: Frequency/Period, Start Phase,
Amplitude/High Level, Offset/Low Level, Pulse Width/Duty Cycle, Rise
Time/Fall Time.
For the setting frequency/period, amplitude/high level, offset/low level, please
refer to Output the sine waveform on page 26
.
