Multimetrix CM603 User Manual

14
Conforms to UL Std. 61010-1, 61010-2-030, 61010-2-033
Certied to CSA Std. C22.2 No. 61010-1, 61010-2-030, IEC std.
61010-2-033.
3.3.6. DIODE TEST
Forward current: 1mAdc environ.
Reverse voltage: 3 Vdc environ.
Function Resolution Display
1mV
The display unit indicates the reverse voltage
of the diode.
3.3.7. CONTINUITY
Open-circuit voltage: 1 Vdc environ.
The instrument emits an audible signal when the measurement is below
approximately 40Ω.
3.3.8. CAPACITY
Range 10 nF 100 nF 1 µF 10 µF 100 µF 1 mF 10 mF
Resolution 1 pF 10 pF 100 pF 1 nF 10 nF 100 nF 1 µF
Intrinsic
uncertainty
± (4% R ±
5 pt)
± (3% R ±3 pt)
3.3.9. TEMPERATURE
Measurement range -20°C ... +1000°C
Resolution 1°C
Intrinsic uncertainty ±(3% R ±3 pt)
3.3. ENVIRONMENTAL CONDITIONS
Operating range: 0 to 40°C and <80%RH without condensation.
Storage range (without batteries): -10 to +60°C and <70%RH without
condensation.
If an extended period of non-use is anticipated, or for storage, withdraw the
batteries from the housing.
For use indoors and outdoors without rain.
Pollution degree: 2.
Altitude: <2000m.
3.4. POWER SUPPLY
The instrument is powered by three 1.5V alkaline batteries (type AAA or LR3).
3.5. CHARACTERISTICS OF CONSTRUCTION
Dimensions (L x l x P) 206 x 79 x 43mm
Clamping diameter 26mm
Mass 270g approx.
Drop test 2m.
3.6. ELECTRICAL SAFETY
Electrical safety 600V CAT III per IEC 61010-1, IEC 61010-032 and IEC
61010-033.
3.7. ELECTROMAGNETIC COMPATIBILITY
Emission and immunity in industrial environment according to IEC 61326-1.
