Multimetrix CM603 User Manual

9
Thank you for purchasing this AC CM603 clamp multimeter.
For best results from your instrument:
 read these operating instructions carefully,
 comply with the precautions for use.
WARNING, risk of DANGER! The operator must refer to these
instructions whenever this danger symbol appears.
WARNING, risk of electric shock. The voltage applied to parts marked
with this symbol may be hazardous.
Equipment protected by double insulation.
Information or useful tip.
Battery. Earth.
Can be applied to or removed from conductors at dangerous voltages.
Type A current sensor per IEC 61010-2-032.
The product is declared recyclable following an analysis of the life
cycle in accordance with standard ISO 14040.
Chauvin Arnoux has adopted an Eco-Design approach in order
to design this appliance. Analysis of the complete lifecycle has
enabled us to control and optimize the effects of the product on
the environment. In particular this appliance exceeds regulation
requirements with respect to recycling and reuse.
The CE marking indicates conformity with European directives, in
particular LVD and EMC.
The rubbish bin with a line through it indicates that, in the European
Union, the product must undergo selective disposal in compliance
with Directive WEEE 2002/96/EC. This equipment must not be treated
as household waste.
ENGLISH
CONTENTS
1. PRESENTATION ...................................................................................10
1.1. Delivery condition ...................................................................10
1.2. Inserting the batteries .............................................................10
1.3. Display unit .............................................................................10
1.4. Presentation of the instrument ................................................10
2. USE .......................................................................................................11
2.1. Voltage measurement .............................................................11
2.2. Frequency and duty cycle measurements ..............................12
2.3. Current measurement .............................................................12
2.4. Resistance, diode, and continuity measurements ..................12
2.5. Capacitance measurement .....................................................12
2.6. Temperature measurement.....................................................12
2.7. AUTO OFF ..............................................................................12
3. CHARACTERISTICS ............................................................................12
3.1. Reference conditions ..............................................................12
3.2. Electrical characteristics .........................................................13
3.3. Environmental conditions .......................................................14
3.4. Power supply ..........................................................................14
3.5. Characteristics of construction ...............................................14
3.6. Electrical safety ......................................................................14
3.7. Electromagnetic compatibility .................................................14
4. MAINTENANCE ....................................................................................15
4.1. Cleaning .................................................................................15
4.2. Replacement of batteries ........................................................15
5. WARRANTY ..........................................................................................15
