MULTISPAN AMP-23 - Page 2

AMP-23
www.multispanindia.com
Page - 2
Connection Diagram
230V AC
50Hz,4VA
1
2
3
4
5
6
7
L
N
!
12
S1
R
Y
B
S2
S2
S2
S1
S1
8
9
10
11
13
14
All safety related codifications, symbols and instructions that appear in this operating manual
or on the equipment must be strictly followed to ensure the safety of the operating personnel as
well as the instrument.
If all the equipment is not handled in a manner specified by the manufacturer, it might impair the
protection provided by the equipment .
=> Read complete instructions prior to installation and operation of the unit.
WARNING : Risk of electric shock.
Safety Precautions
Current: 0.1 To 5A AC, CAT III
Range
CT Selection up to 6000/5 Amp AC CAT III
R Phase Ampere
R
R
R
R
Y
Y
Y
Y
B
B
B
B
Y Phase Ampere
B Phase Ampere
Average Current
LED INDICATION
