MULTISPAN AVH 13N - Page 3

Page-6 : KWH Page
3P-4W
Display Line 1
Display Line 2
Display Line 3
KWH
Value
AVH 13N
Freq
0 0
0 0 5 0
.
Page-5 : KVA & Freq. Page
3P-4W
Display Line 1
Display Line 2
Display Line 3
KVA
Freq
AVH 13N
Freq
0 6 9 5
.
5 0 0
.
Page-3 : Amp Page
3P-4W
Display Line 1
Display Line 2
Display Line 3
IR
IY
AVH 13N
Freq
5 0 0 0
.
4 9 5 0
.
4 8 7 0
.
IB
Page-4 : L-L Voltage Page
3P-4W
Display Line 1
Display Line 2
Display Line 3
VRY
VYB
VRB
AVH 13N
Freq
3 2 0 5
.
3 2 0 5
.
3 2 0 5
.
Note:
1) The meter supplied under this terms & condition are not
to be used as a standard meter/Revenue meter or not for
calibration of other meter, unless specified by Multispan.
2) It is suggested that external CT Should be selected in such
a way that actual load does not fall below 40% of the
Ampere rating of external CT. This will help in achieving
more accurate results of cumulative energy values over a
period of time. For example, external CT is 100/5 A then
accuracy will be good at load more than 40 Ampere.
3) Above reading are recorded with respect to direct source
and without external CT connection. In field application
accuracy class of externally connected CT will affect the
accuracy of the meter readings.
±0.5% of Full scale
Accuracy
Current
Active Power
Power Factor
Reactive Power
Apparent Power
Voltage V
L-L
Voltage V
L-N
Reactive Energy
Apparent Energy
Active Energy
±0.5% of Full scale
±0.5% of Full scale
Class 1
Measurment Acuuracy
Class 1
Class 1
Class 1
Class 1
Class 1
Class 1
