MULTISPAN PTC-4202A-M1 - Page 5

www.multispanindia.com
Page-5PTC-4202A-M1
R/W
40018
30009
LowRange.
DP=0:-999to9999.
DP=1:-99.9to999.9
DP=2:-9.99to9.99
DP=3:-0.999to0.999.
-999to+9999
40020
30010
HighRange.
R/W
R/W
40022
30011
OffsetAnalog
DP=0:-999to9999.
DP=1:-99.9to999.9
DP=2:-9.99to9.99
DP=3:-0.999to0.999.
-999to+9999
40024
30012
CorrectionFactor.
R/W
40026
30013
FilterTime.
R/W
0.1to10.0Sec
1to100Sec
40028
30014
SignalLowLimit.
R/W
0.0to5.0
0to50
40030
30015
ControllAction.
R/W
CTRL=1PID
CTRL=0ONOFF
CTRL=1PID
CTRL=0ONOFF
40032
30016
ControllMode.
R/W
CTRL=1HEAT
CTRL=0COOL
CTRL=1HEAT
CTRL=0COOL
40034
30017
Set2Mode.
R/W
S2MD=0Individual.
S2MD=0Relative.
S2MD=0Individual.
S2MD=1Relative.
40036
30018
Relay2Mode.
R/W
R2MD=0OFF.
R2MD=1H-AL.
R2MD=2L-AL.
R2MD=3IN-B.
R2MD=4OT-B.
R2MD=5AB-LO.
R2MD=6AB-OT.
R2MD=0OFF.
R2MD=1H-AL.
R2MD=2L-AL.
R2MD=3IN-B.
R2MD=4OT-B.
R2MD=5AB-LO.
R2MD=6AB-OT.
40038
30019
Set3Mode.
R/W
S3MD=0Individual.
S3MD=1Relative.
S3MD=0Individual.
S3MD=1Relative.
40040
30020
Relay3Mode.
R/W
R3MD=0OFF.
R3MD=1H-AL.
R3MD=2L-AL.
R3MD=3IN-B.
R3MD=4OT-B.
R3MD=5AB-LO.
R3MD=6AB-OT.
R3MD=0OFF.
R3MD=1H-AL.
R3MD=2L-AL.
R3MD=3IN-B.
R3MD=4OT-B.
R3MD=5AB-LO.
R3MD=6AB-OT.
40042
30021
ProporationalBand(PB.)
R/W
40044
IntegralTime(IT).
R/W
40046
DerevativeTime(DT).
R/W
40048
CycleTime(CT).
R/W
30022
30023
30024
0-9999
1-99Sec.
0-9999
1-99Sec.
R/W
40016
30008
DecimalPoint(DP).
DP=0:0000
DP=1:000.0
DP=2:00.00
DP=3:0.000
DP=0:0000
DP=1:000.0
DP=2:00.00
DP=3:0.000
