Page-6 PTC-4202A-M1
R/W
40050
30025
ManualReset(MR).
INPT=0:
INPT=1:-9to9
INPT=2:
INPT=3:-9.to+9.0
INPT=4:
INPT=5:-99to+99
INPT=6:
INPT=0:
INPT=1:-9to9
INPT=2:
INPT=3:-90to+90
INPT=4:
INPT=5:-99to+99
INPT=6:
R/W
40054
30027
Hysteresys2.
INPT=0:
INPT=1:1to50
INPT=2:
INPT=3:0.1to50.0
INPT=4:DP=01to
999.
INPT=5:DP=10.1to
99.9
DP=20.01to
9.99
INPT=6:DP=30.001to
0.999.
INPT=0:
INPT=1:1to50
INPT=2:
INPT=3:1to500
INPT=4:
INPT=5:
INPT=6:
R/W
40052
30026
Hysteresys1.
R/W
40056
30028
Hysteresys3.
1to999
R/W
40058
30029
CoolingDelayTime
1to999Sec 1to999Sec
R/W
40060
30030
OutputType
0=forward
1=reverse
0=forward
1=reverse
R/W
40062
30031
LowPR.(LOPC)
0to100 0to100
R/W
40064
30032
HighPR.(LOPC)
0to100 0to100
R/W
40066
30033
SourceMode
0=auto
1=manual
0=auto
1=manual
R/W
40068
30034
ControlOutput(%)
0to100 0to100
R/W
40070
30035
StatusofRelay2
0=ON1=OFF 0=ON1=OFF
R/W
40072
30036
StatusofRelay3
0=ON1=OFF 0=ON1=OFF
R/W
40074
30037
Tuning
1=ON
0=OFF
1=ON
0=OFF
R
40076
30038
SensorCondition
0=Normal
1=Open
2=Over
3=Low
0=Normal
1=Open
2=Over
3=Low
R
40078
30039
Address
1to128 1to128
