POWER DRAW
Conduit
®
Cat 4 for EU/UK MTCDT-L4E1 Hardware Guide 13
Chapter 3 – Power Draw
Power Draw
MTCDT-L4E1-247A with Modem and No Accessory Cards
Radio Protocol Cellular Connection
no data (mA)
Measured Current at
Max Power (mA)
TX Pulse (AVG)
Amplitude Current
for GSM850 or Peak
Current (mA)
1
Total Inrush Charge
(mC)
2
9.0 Volts
eGSM 900 MHz 163 423 1,650 5.25
WCDMA 162 617 728 5.25
LTE 236 602 688 5.25
12.0 Volts
eGSM 900 MHz 154 326 1,210 4.68
WCDMA 141 489 584 4.68
LTE 175 465 556 5.68
24.0 volts
eGSM 900 MHz 104 191 635 3.63
WCDMA 95 282 360 3.63
LTE 115 265 316 3.63
1
Tx Pulse: The average peak current during a GSM850 transmission burst period. The transmission burst duration
for GSM850 can vary, depending on what transmission scheme is being deployed (GPRS Class 8, Class 10, GSM,
etc.).
2
Total Inrush Charge: The total inrush charge at power on expressed in Millicoulombs (mC).
Note:
Multi-Tech Systems, Inc. recommends that you incorporate a 10% buffer into the power source when
determining product load.
