Chapter 1 - Description and Specifications
4 Multi-Tech Systems, Inc. MT9234ZPX User Guide
Chapter 1 – Description and Specifications
ProductDescription
The Multi-Tech MultiModem ZPX is an internal universal PCI bus card, MT9234ZPX-UPCI or a PCI Express bus
card, MT9234ZPX-PCIE. The UPCI card operates in either 3.3 or 5V slot. The PCI Express card operates in a 3.3V
slot.
The MultiModem provides high-speed data transfer and fax capabilities for small businesses, telecommuters, and
SOHO users. It is compatible with the IUT-T V.92 protocol that provides quick connections, downstream
transmissions at speeds up to 56K bps*, and upstream transmissions speeds up to 48K bps when connected to
V.92-compatible Internet service providers. Transmissions between the MultiModem and other client modems are
limited to 33.6K bps, as are upstream transmissions to non-V.92-compatible ISPs and downstream transmissions
that are converted more than once on the telephone network.
* Though this modem is capable of 56K bps download performance, line impairments, public telephone infrastructure, and other
external technological factors currently prevent maximum 56K bps connections.
MT9234ZPX-UPCI
MT9234ZPX-PCIe
Features
• V.92/56K download speeds and 48K upload speeds when connecting with V.92 servers
• V.44 compression improves data throughput rates
• Class 1.0 and Class 2.1 faxing at speeds to V.34/33.6K bps (Super G3)
• Error Correction Mode (ECM) provides fast and reliable fax transmissions
• Voice support for voice mail and full duplex speakerphone (voice models only)
• U.S. Caller ID reporting
• Global approvals in many countries for worldwide use
• Telco adapters available for country localization
• Built-in processor that does the work, so your computer doesn’t have to
• Remote configuration for centralized setup and management
• DTMF tone detection
• Flash memory for easy updates
• Two-year warranty
PackageContents
• one MultiModem
• one RJ-11 telephone cable
• one Quick Start Guide
• one product CD
• One low profile mounting bracket (MT9234ZPX-PCIe models only)
ATCommandInfo
AT commands for the wireless modem are published in a separate Reference Guide included on the product CD
and posted on the Multi-Tech web site.
