Chapter 1 - Description and Specifications
Multi-Tech Systems, Inc. MT9234ZPX User Guide 5
TechnicalSpecifications
Category Description
Receiver AGC Dynamic Range
43 dB
Data Compatibility
V.92, V.34 enhanced, V.34, V.32bis, V.32, V.22bis, V.22; Bell 212A and 103/113, V.21
& V.23
Data Format
Serial, binary, asynchronous
Error Correction (ECM)
Data Mode V.44; V.42 LAPM, MNP 2-4
Fax Mode T.30 Annex A & C
Data Compression
V.42bis & MNP Class 5
Fax Compatibility
V.34, V.17, V.29, V.27, & V.21 Ch. 2
Fax Classes
Class 1 &1.0 and Class 2, 2.0 &2.1
Fax Data Rates
33,600; 31,200; 28,800; 26,400; 24,000; 21,600; 19,200; 16,800; 14,400; 12,000;
9600; 7200; 4800; 2400; 1200; 0-300 bps
Fax Compression
MH, MR, MMR
Command Buffer
80 characters
DAA Isolation
1500 Vac
Dimensions
UPCI – 6.03” L X 4.76” W
15.31 cm L x 12.09 cm W
PCIe with Standard Bracket – 7.13” L x 4.76” W
18.11 cm L x 12.09 cm W
PCIe with Low Profile Bracket – 7.13” L x 3.16” W
18.11 cm L x 8.02 cm W
Flow Control
XON/XOFF (software), RTS/CTS (hardware)
Frequency Stability
±0.01%
Modes of Operation
Fax online mode; full duplex over dial-up lines; data mode; command mode; online
command mode; V.54 test mode
Operational Temperature
-5 to+60° C (23° to 140°F) humidity range 20–90% (non-condensing)
Storage Temperature
-40 to +85°C (-40° to 185° F)
Power Requirements
3.3 or 5 volt slot (Universal PCI) 3.3 volts (PCI Express)
Voice Compatibility
TAM (Telephone Answering Machine): S-101 AT+V commands (no CODEC for
speakers/microphone interface)
Serial Speeds
Serial port data rates adjustable to 300, 1200, 2400, 4800, 9600, 19,200, 38,400,
57,600, 115,200, and 230,400 bps
Transmit Level
-11 dBm (varies by country setting)
Receiver Sensitivity
-43 dBm under worst-case conditions
Cleaning
No cleaning/washing due to the manufacturing process used to produce this product.
Manufacturing Information
Trade Name: MultiModem
®
ZPX
Model Number: MT9234ZPX
Registration No: AU7MM01BMT9234SMI
Ringer Equivalence: 0.1B
Modular Jack (USOC): RJ11
Approvals
CE Mark
Telecom
47CFR Part 68
CS03
TBR21
Safety Certifications
UL/cUL 60950-1
EN60950-1
AS/NZS 60950:2000
CCC
EMC Approvals
FCC Part 15, Class B
ICES-003, Class B
EN 55022, Class B
EN 55024
