Multitech MultiConnect rCell 100 Series User Manual

PRODUCT OVERVIEW
Power Draw
GPRS
Typical Maximum Peak TX Peak Rst (Inrush
Current)
7 volts
0.305A, 2.14W 0.495A, 3.47W 1.74A 2.30A
9 volts
0.230A, 2.12W 0.332, 3.05W 1.28A 4.12A
20 volts
0.111A, 2.22W 0.164A, 3.28W .520A 3.03A
32 volts
0.075A, 2.40W 0.112A, 3.58W 0.337A 2.50A
HSPA
Typical Maximum Peak TX Peak Rst (Inrush
Current)
7 volts
0.417A, 2.92W 0.625A, 4.38W 0.792A 2.30A
9 volts
0.272A, 2.52W 0.455, 4.18W 0.588A 4.12A
20 volts
0.140A, 2.80W 0.216A, 4.32W .320A 3.03A
32 volts
0.090A, 2.88W 0.155A, 4.96W 0.250A 2.50A
Note: Multi-Tech Systems, Inc. recommends that you incorporate a 10% buffer into the power source when
determining product load.
RF Specifications
GSM 850 EGSM GSM 1800 GSM 1900
Frequency RX 869 to 894 MHz 900 925 to 960 MHz 1805 to 1800 MHz 1930 to 1990 MHz
Frequency TX 824 to 849 MHz 880 to 915 MHz 1710 to 1785 MHz 1850 to 1910 MHz
MultiConnect
®
rCell 100 Series Router User Guide 13
