Multitech MultiConnect rCell 100 Series User Manual

CELLULAR INFORMATION
GPS Antennas
GPS Antenna Specifications
Category Description
Frequency Range 1575.24 MHz
Impedance 50 Ohms
VSWR 2.0:1 max
Gain 10-30 dBi
LNA Current Consumption 40 mA max
Noise Figure < 2dB
Polarization RHCP
Input voltage 3.0V ± 0.2V
Bluetooth and Wi-Fi Antennas
Manufacturer: Taoglas Antenna Solutions
Manufacturer's Model Number: GW.11.A153
Multi-Tech Systems: 45009740L
Multi-Tech Ordering Information
Model Number Quantity
ANWF-1HRA 1
ANWF-10HRA 10
ANWF-50HRA 50
Antenna Specifications
Category Description
Frequency Range 2.4000 to 2.4835 GHz
Impedance 50 Ohms
VSWR VSWR should not exceed 2.0:1 at any point across the bands of operation
Peak Radiated Gain 2.3 dBi on azimuth plane
Radiation Omni-directional
Polarization Linear Vertical
Connector RP-SMA(M)
18 MultiConnect
®
rCell 100 Series Router User Guide
