3.7 Foundation
Thedehumidifier must be installed on a level floor, or platform, which has been designed with a floor
loading capacity c apable of supporting the machine’s weight. If the maximum floor loading weight is not
exceeded, special foundations are not required.
When the dehumidifier has been installed, it should be checked that it is level. If local regulations require that
the unit is permanently fixed in position, the fixing holes can be used for bolting the unit to the floor.
D
47
47
E
B
A/2
A
C
F
Ø 13,5
G
Figure 3.2 Mounting base
MX² 30 MX² 35–55 MX² 60–95
Dimension (mm) Dimension (mm) Dimension (mm)
A
600 880 970
B
110 94 151
C26 25 25
D 800 1063 1063
E
811
1068
1272
F
101 94 151
G
Centerline
Table 3.1 Mounting base dimensions
