CAUTIO N!
Failure tocorrectlyadjusttheairflows cancausemalfunctionofthe unit.
Anydamageto the unitresulting fromincorrectadjustment oftheairflowscaninvalidatethe warrantyof theunit.
Theairflows mustneverbe setabovetheratedairflowswithoutconsulting Munters forverification.
4.2.2 Settingtheratedairflows
Process fan control with xed speed
1. Calculate the cor responding differential pressures for the actual process and reactivat ion airows. Use
the formula and the fan coefcients in section 4.2.3, Base conguration settings.
2. Star t the unit by setting the mode switch in position MAN.
3. Connect a manometer to the pressure nipple on the proces s f an. Measure and record the differential
pressure.
4. Compare the measured differential pressure w ith the calculated value.
5. Adjust the settings for the proce ss airow in the control system, so the m easured differential pressure
value corresponds to the calculated value.
6. Connect the manometer to the pressure nipple on the reactivation fan. Repeat the procedure in step 3–5
to set the actual reactivation airow.
NOTE!
Theactual airflowisdependantonthe temperatureatthe fanoutlet.
Process fan control w ith variable speed
1. Star t the unit by setting the mode switch in position AUTO.
2. Set t he required process airow or process air pressure in the control system.
3. Measure the actual process airow external to the dehumidier using exter nal, calibrated test
equipment.
4. If necessar y, adjust the settings for process air ow or process air pressure in the control system.
5. Set t he required reactivation airow in the control system.
6. Measure the actual reactivation airow exte rnal to the dehumidi er using external, calibrated test
equipment.
7. If necessa ry, adjust the settings for the react ivation airow in the contro l system.
4.2.3 Base configurationsettings
Δ
p
=
q
k
(
2
)
Figure 4.1 Formula for calculatio n of differential pr essure
p = Differential pressure (Pa)
q=Airow (m
3
/h)
k=Fancoefcient
32
Commissioning
190TEN–1089–G1412
