Munters MX2 60 - Duct Connection Dimensions, Process Fan

3.11.7 Ductconnectiondimensions,processfan
A
MX² 30-95S
A
MX² 30
C
M8 (8x)
283
222
218
218
12
12
128128
460
414
307
243
(2x)
12
12
141,5
(2x)
510
C
M8 (8X)
A
247
450
MX² 35-55
23,5273
333
560
25
500
12
175
(3x)
12
154,5
(2x)
C
M8(10x)
A
MX² 60-95
Figure 3.8 Process air outlet (dry air outlet)
C. Use hexagon head bolts (M8 x 25).
28 Installation 190TEN–1089–G1412
