Munters WM54 - Page 39

39 | © Munters AB, 2019
REF.
DESCRIPTION
QTY
1
FIBERGLASS HOUSING
1
2
ALUMINUM STRUCTURE
1
3
BUTTERFLY COMPLETE ASSEMBLY
1
4
POLYETILENE CONE SECTOR
4
5
ROUND SAFETY GRID
1
6
CABLE
1
7
DRIP SHIELD
1
9
HUB WITH BEARING ASSEMBLY
1
9
CENTRAL PULLEY
1
10
WATERPROOF DISTANCE PIECE
1
11
ANGULAR PLATE
4
12
BELT TENSIONER PULLEY
1
13
BELT TENSIONER
1
14
PLATE FOR BELT TENSIONER
1
15
CENTRAL SUPPORT
1
16
MOTOR PLATE
1
17
BRACKET,MOTOR MOUNT STIFFENER
1
18
ELECTRICAL MOTOR
1
19
MOTOR PULLEY
1
20
V-BELT A61
1
21
CONE BRACKETS
4
22
PLASTIC CLIP
12
23
REAR SAFETY MESH CUTTED
1
24
STEEL CLAMP
4
25
CAP COVER NUT
1
26
SPRING TENSIONER
2
27
M25 HEX NUT
1
28
M8x45 HEX SCREW
4
29
Ø8×32 WASHER
29
30
M8 HEX NUT W/FLANGE
33
31
M8X30 HEX SCREW
18
32
M8×20 HEX SCREW
1
33
Ø6.3×19 SELF-TAPPING SCREW
2
34
M4.8×13 HEXAGONAL HEAD SELF-TAPPING SCREW
8
35
M8×25 HEX SCREW
4
36
SPRING WASHER Ø8 X 15
4
37
HEX NUT M6 WITH FLANGE
4
38
M8 HEX NUT
4
39
M6×30 HEX SCREW
4
40
M8×65 HEX SCREW
7
41
M10×50 HEX SCREW
1
42
Ø10 GROWER WASHER
1
43
M10×25 HEX SCREW
1
44
PLAIN WASHER D08x24
4
45
GROWER WASHER Ø8.4 x 14.4
1
46
PROPELLER
1
