4. UNPACKING THE EQUIPMENT
WARNING
Failure to respect safety or behavioral rules can produce hazardous situations for users as well as
damage to the machine and the place where it is installed. The fan must only be used if it is in perfect operating
condition, by personnel who are perfectly aware of the safety measures and possible hazards, and in strict
compliance with the instructions given in this manual.
4.1 Personnel Requirements
Equipment may only be used by personnel who know and apply the specific requirements given in the user and
maintenance manual and the more general instructions contained in various regulations for accident prevention and
applicable legislation regarding safety in the workplace, as well as other European Community directives incorporated by
the member states into their national legislation.
Knowledge and understanding of the manual and of the attached documents constitute an indispensable tool for reducing
hazards and promoting the safety and health of workers.
WARNING
Operators must be trained to deal with the occurrence of possible faults, malfunctions or dangerous
conditions to themselves or others, and in such an event must:
• stop the fan immediately by operating the emergency stop device (mushroom-shaped pushbutton/main
switch mounted on the electrical panel);
• not carry out operations which are beyond their duties and/or technical knowledge.
4.2 Part List
Each WM54F requires:
1 – 54” Fiberglass Orifice
1 – 54” Propeller
1 – Central Support
1 – Motor
1 – Motor pulley
1 – Drip Shield
1 – Main Frame Assembly
1 – Plastic Door Assembly
4 – Plastic Cone Sections
1 – Round Safety Mesh
1 – Flat Safety Mesh
1 – Motor slide
1 – Tensioner bracket
4 – Cone Support Brackets
4 – Cone/Strut Mounting Bracket
1 – V-belt
1 – Hub with Bearings & Shaft
1 – Central Pulley
1 – Belt tensioner
1 – Motor stiffener bracket
2 – Tension Spring
1 – Cable
Bolts and Nuts
