Mutec MC-3+ Smart Clock USB - Appendix; Technical Specifications

XX XX
28
USB In- & Output (USB I/O)
Interface 1 x USB-B connector
Formats & Resolutions Type 1 Formats: PCM 16 bit, PCM 24 bit, PCM 32 bit, FLOAT 32 bit für USB 1.0 & USB 2.0
Supported PCM Sampl. Rates USB 1.0: 44.1 kHz & 48.0 kHz, USB 2.0: 44.1 kHz to 192.0 kHz
Supported DSD Sampl. Rates DSD64, DSD128, DSD256
Supported DoP Sampl. Rates DoP64, DoP128
Word Clock & 1–10.0 MHz Input (WCLK
&
10.0M IN)
Interface 1 x BNC, 200 mV-7 V, unbalanced, input impedance 75 Ω (can be switched off, see Page 24/25)
Formats & Resolutions Word Clock, Word Clock × 256, so-called atomic clocks & GPS clock references
Supported Clock Rates 32.0 kHz to 192.0 kHz, 1,0-, 2,5-, 5,0-, 10.0 MHz, 11.2896 MHz, 12.2880 MHz
AES3/11 Input (AES3/11 IN)
Interface 1 x XLR female, transformer balanced, input impedance 110 Ω, 200 mV–7.0 V
Formats & Resolutions AES3-1992/2003, AES11-1997/2003, IEC 60958, 16–24 bits
Supported Sampling Rates 32.0 kHz to 192.0 kHz
S/P-DIF & AES3id Input (S/P-DIF & AES3id IN)
Interface 1 x BNC, 200 mV-7 V, unbalanced, input impedance 75 Ω
Formats & Resolutions S/P-DIF: IEC 60958, 16 –24 bits, AES3id: AES3id-2001 (rev. 1995) or AES11-2003 (rev. 1997)
Supported Sampling Rates 32.0 kHz to 192.0 kHz
S/P-DIF optischer Input (S/P-DIF IN, OP)
Technical Data
Interface 1 x Toslink
TM
, EIAJ RC-5720
Formats & Resolutions IEC 60958, 16–24 bits
Supported Sampling Rates 32.0 kHz to 192.0 kHz
Word Clock Outputs (WCLK OUT 1–2)
Interface 1 x BNC, 200 mV–7 V, unbalanced, input impedance 75 Ω
Formats & Resolutions Word Clock, Word Clock × 256, so-called »Super Clock«
Supported Clock Rates 32.0 kHz to 192.0 kHz
AES3/11 Output (AES3/11 OUT 4)
Interface 1 x XLR male, transformer balanced, 3.5Vpp @ 110Ω, output impedance 110 Ω, buffered
Formats & Resolutions AES3-1992/2003, AES11-1997/2003, IEC 60958, 16–24 bits
Supported Sampling Rates 44.1 kHz to 192.0 kHz
AES3id Output (AES3/11id OUT 4)
Interface 1 x BNC, 1 V, unbalanced, input impedance 75 Ω, buffered
Formats & Resolutions AES3id: AES3id-2001 (rev. 1995) or AES11-2003 (rev. 1997), 16 -24 bits
Supported Sampling Rates 44.1 kHz to 192.0 kHz
S/P-DIF BNC Output(S/P-DIF OUT 3)
Interface 1 x BNC, 0.5 V, unbalanced, input impedance 75 Ω, buffered
Formats & Resolutions IEC 60958, 16–24 bits
Supported Sampling Rates 44.1 kHz to 192.0 kHz
S/P-DIF optical Output (S/P-DIF OUT 3, OP)
Interface 1 x Toslink
TM
, EIAJ RC-5720
Formats & Resolutions IEC 60958, 16–24 bits
Supported Sampling Rates 44.1 kHz to 192.0 kHz
S/P-DIF RCA Output (S/P-DIF OUT 3, CO)
Interface 1 x Coaxial (RCA female), unbalanced, 0.5 Vpp @ 75 Ω, output impedance 75 Ω, buffered
Formats & Resolutions IEC 60958, 16–24 bits
Supported Sampling Rates 44.1 kHz to 192.0 kHz
Appendix
