MUTOH XPJ-661UF - Loading Media onto the Printer

Loading media 33
Loading media
Important!
• When loading a new media, make sure to place it on an appropriate position and input correct media information.
If wrong information is entered, the printer can print on an unintended position of the table. Once UV ink stains on the table,
it will be cured by UV lamp and will not be removed from the table.
• When using this product, do not place any object in the sensing area of the obstacle detection sensor. This will cause false
detection and the printer will not be able to print correctly.
For details, see the following section:
"Printing area" P. 32
1. Placing the media on the table
[1]
Check that the message on the left is displayed.
If not displayed, tap .
[2]
Hold the handle on the front cover to gently open it.
The message on the left will appear.
Note
When using the optional vacuum table, you can change the vacuum power of
the current job by tapping or while the message on the left appears
on the panel. The vacuum power can be selected between 0 and 4 (0: turn the
vacuum fan off).
The vacuum fan turns on by tapping or .
The change made will be saved in the user type currently selected.
Setmedia,then
Tap[∧]key.
2
Set media, then
close cover.
