iVector S2
Installation manual
iVector S2 • 2022-07-01
US
A
B
B C
Cleaning the filter
• Remove any dust with a vacuum cleaner.
• Wash the filter with clean running water. Do not use
detergents or solvents.
• Leave to dry.
• Re-fit the filter taking care to insert the lower back
edge into its seat.
Never use the unit without filters
The appliance is fitted with a safety switch that
prevents operation of the fan with the front
grille missing or out of position.
After refitting the filter, check that the grille is
correctly mounted.
A Filter C Filter locating channel
B Lower edge
• To refit the grille, insert the two lugs into the lower
slots, rotate it and attach to the upper chassis slots.
A Tabs B Slots
A
B
Energy saving tips
• Always keep the filters clean and as far as possible
keep the doors and windows closed in the room being
conditioned when the unit is in use.
• Limit where possible the effect of direct sun rays in
the rooms being conditioned (use curtains, shutters
etc.)
