4 of 53
GT1175 (H105 Medium) Hurricane Quick Set-Up and Parts Guide www.NabcoEntrances.com
P/N C-00106 Rev 8-10-16
Table 2-1 Suggested types of Anchors
A 1/4 inch Tapcon by ITW with 1-3/4 inch minimum embedment into 3000 PSI Concrete 2-1/2 inch
A1 5/16 inch Tapcon by ITW with 1-3/4 inch minimum embedment into 3000 PSI Concrete 2-3/16 inch
B 1/4 inch Tapcon by ITW with 1-1/4 inch minimum embedment into Hollow Block 2-1/2 inch
C 1/4 inch Tapcon by ITW with 1-1/2 inch minimum embedment into PT WOOD (SG=0.55) 1 inch
C1 5/16 inch Tapcon (Fy=115 Ksi) by ITW with 1-1/2 inch minimum embedment into PT WOOD (SG=0.55) 1-1/4 inch
D 1/4-14 GR 5 Sheet Metal screws into 1/8 inch metal structures 1/2 inch
D1 5/16-18 GR 5 Sheet Metal screws into 1/8 inch metal structures 1 inch
X Minimum embedment are beyond wall dressing.
X Tapcons with at, hex and/or pan heads can be used.
X Metal structures are ASTM A36 Steel or 6063-T6 Aluminum.
X Anchor Type D must have a minimum (3) threads embedment.
X Header & Jamb anchors are installed into a single row.
X Sill anchors are distributed into (2) in line rows.
Table 2-2 Framing Sill Track Anchorage Capacity in PSF Function of Anchor Type and Number of Pair Clusters
92 36 105 70
39 97 65
42 90 60
45 84 56
48 79 53
54 70 47
96 36 101 67
39 93 62
42 87 58
45 81 54
48 76 51
52 70 47
100 36 97 65
39 90 60
42 83 55
45 78 52
48 73 48
49 70 47
104 36 93 62
39 86 57
42 80 53
45 75 50
48 70 47
* FH = Framing Header ** DM = Dimension
