Page 11 www.NabcoEntrances.com 04-24-08
U30 Electrical Installation Manual
D.1.5 Wiring Diagram for connecting push plates and or card readers for use in Night mode. Attach the normally
open contacts across terminals 16 & 6 on controller terminal block.
MAGNETIC POWER
DOWN SWITCH PT.
NO. 22-9222
KEY PAD OR CARD READER ON
SECURE SIDE OF DOOR
(N.O. - DRY CONTACTS)
N.O.
COM
TO
AUXILIARY
POWER
SUPPLY
MAIN HARNESS
FOR U30
PN 24-11877
PT. NO. 14-8902
INTERIOR ACUSENSOR EXTERIOR ACUSENSOR
PT. NO. 14-8902
ACUSENSOR
EXTENSION
HARNESS
P/N 22-9267-00
ACUSENSOR
EXTENSION
HARNESS
P/N 22-9267-00
YELLOW
RED
GRAY
YELLOW
RED
GRAY
2
3
4
5
6
7
8
9
10
11
16
15
14
13
12
TERM. # 1
Optex OS-12C
Controller
BLUE
BLUE
BLUE
WHITE
WHITE
ORANGE
GREEN
RED
ORG/WHT
BLUE
WHITE
WHITE
LABEL ON U30 CONTROL
DN 0291
RED
ROCKER SWITCH
EXTENSION HARNESS
FOR U30
PT. 14-11884
ROCKER SWITCH
FOR U30
PN 14-11875
BACK SIDE OF
ROCKER SWITCH SHOWN.
ON
OFF
NIGHT
TWO WAY
ONE WAY
HOLD OPEN
FULL
OPEN
REDUCED OPEN
ORG/WHT
ORG/WHT
GREEN
BLUE
RED
RED
ORANGE
RED
RED
ORANGE
KEY SWITCH
FOR U30
PN 14-11876
TERMINAL ON U30 CONTROL
P/N 14-11873
TER # 16
TER # 6
OPTEX
HOLDING BEAM
CONTROLLER
PT. NO.
14-9710-03
WHITE
YELLOW
BROWN
RED
BLACK
WHITE
GREEN
ORANGE
ORG/WHT
BLK/RED
BLUE
RED
RED
BLK
BROWN
BROWN
BLK/RED
RED
12VDC-COMMON
Auxiliary Output (Open-Collector)
Sequential Activation
5Amax.(0-20V), 3.2Amax.(20-30V)
30V(42.4Vpeak)max.
Contact Output (Class2 Load only)
FUNCTION [SLIDING DOOR]
REDUCED OPENING SWITCH
Breakout Detector
Sidelite Presence Sensor
Exterior Activation
HOLDING BEAM
INTERIOR ACTIVATION
12VDC-(COMMON)
12VDC+
Mode Switch (see Mode SW Usage shown left)
Common
N/C
N/O
SQ
OUT
OUT.A
OUT.B
OUT.C
7
SYMBOL
BA
62
SLS
M1
H
M0
6B
9DC12V
7
61
12
13
14
15
16
No.
11
10
9
8
7
6
5
4
3
2
1
RELATED DEVICES - 16P
