Page 18 www.NabcoEntrances.com 04-24-08
U30 Electrical Installation Manual
D.4 Custom Wiring
D.4.1 Wiring diagram for U30 configured for remote control - TWO WAY and ONE WAY mode. Internal transistor
for signal at fully open or fully closed position.
MAGNETIC POWER
DOWN SWITCH PT.
NO. 22-9222
THIS MODIFICATION IS
FOR USE ON REMOTE
CONTROLLED UNITS
KEY PAD OR CARD READER ON
SECURE SIDE OF DOOR
(N.O. - DRY CONTACTS)
RED (7)
ORANGE (M0)
ORANGE / WHITE (M1)
BLACK RED
N.O.
COM
CARD READER
HARNESS ASSY
P/N 22-9174-20
RED
INTERNAL TRANSISTOR FOR SIGNAL AT THE FULLY
OPEN OR FULLY CLOSED POSITION.
REFER TO AUXILIARY OUTPUT 2 SETTING IN
PROGRAMMING MANUAL
NOTE:
1. MAXIMUM 50 mA
2. IF USING AN EXTERNAL 12 VDC RELAY,
INTERNAL RESISTANCE OF COIL MUST
BE 240 OHMS OR GREATER.
DN 0291
YELLOW
BRN/YEL
GREEN
ORANGE
ORG/WHT
BLK/RED
BLUE
RED
12VDC-COMMON
Auxiliary Output (Open-Collector)
Sequential Activation
5Amax.(0-20V), 3.2Amax.(20-30V)
30V(42.4Vpeak)max.
Contact Output (Class2 Load only)
FUNCTION [SLIDING DOOR]
REDUCED OPENING SWITCH
Breakout Detector
Sidelite Presence Sensor
Exterior Activation
HOLDING BEAM
INTERIOR ACTIVATION
12VDC-(COMMON)
12VDC+
Mode Switch (see Mode SW Usage shown left)
Common
N/C
N/O
SQ
OUT
OUT.A
OUT.B
OUT.C
7
SYMBOL
BA
62
SLS
M1
H
M0
6B
9DC12V
7
61
12
13
14
15
16
No.
11
10
9
8
7
6
5
4
3
2
1
RELATED DEVICES - 16P
1
2
3
4
5
6
7
8
9
10
11
16
15
14
13
12
BLUE
BLUE
BLUE
WHITE
WHITE
ORANGE
GREEN
RED
ORG/WHT
BLUE
WHITE
WHITE
LABEL ON U30 CONTROL
TERMINAL ON U30 CONTROL
P/N 14-11873
MAIN HARNESS
FOR U30
PN 24-11877
ROCKER SWITCH
EXTENSION HARNESS
FOR U30
PT. 14-11884
WIRE NUT
P/N 14-1218
REMOTE CONTROLLED EXTERNAL SWITCH
SWITCH OPEN: TWO WAY MODE
SWITCH CLOSED: ONE WAY MODE
(DRY CONTACTS)
CUT ROCKER SWITCH
EXTENSION HARNESS
AND SPLICE AS SHOWN
NOTES:
1. OTHER WIRES NOT SHOWN FOR SIMPLICITY
2. REMOTE SWITCH CONTACTS MUST BE DRY
(NO VOLTAGE)
3. CAP OFF ALL UNUSED WIRES
ORANGE
GREEN
RED
ORG/WHT
BLUE
