NAD C 320BEE - Parts List - Inductors, Connectors, Relays; Component Listing

PART NUMBER PARTS LOCATION
DESCRIPTION
07-20512-10 Metal Film Resistor 5.1K
,
1/4W
,
5% R359 R360
07-21402-10 Metal Film Resistor 14K
,
1/4W
,
5%
(
OMIT
)
R319 R320
07-20202-10 Metal Film Resistor 2K
,
1/4W
,
5% R412
07-20222-10 Metal Film Resistor 2.2K
,
1/4W
,
5% R414
07-24301-00 Metal Film Resistor 4.3K/1/2W 1% R146 R246
07-21500-10 Metal Film Resistor 150R
,
1/4W
,
1% R149 R249
07-10330-00 Carbon Film Resistor 33R
,
1/6W
,
5% RI2
07-10101-00 Carbon Film Resistor 100R
,
1/6W
,
5% C8
07-10102-00 Carbon Film Resistor 1K
,
1/6W
,
5% RI1
,
RI3
07-10100-10 Carbon Film Resistor 10R,1/4W,5%
R136 R137 R154 R155
R236 R237 R254 R255 R2
R514 R515 R516
07-10220-10 Carbon Film Resistor 22R
,
1/4W
,
5% R142 R143 R242 R243
07-10330-10 Carbon Film Resistor 33R
,
1/4W
,
5% R115 R116 R215 R216
07-10390-10
Carbon Film Resistor 39R
,
1/4W
,
5% R107 R108 R207 R208
07-10680-10 Carbon Film Resistor 68R
,
1/4W
,
5% R335 R336
07-10470-10 Carbon Film Resistor 47R
,
1/4W
,
5% R119 R219
07-10820-10 Carbon Film Resistor 82R,1/4W,5%
R103 R106 R111 R112
R120 R203 R206 R211
R212 R220
07-10101-10 Carbon Film Resistor 100R,1/4W,5%
R1 R3 R14 R24 R416 R417
R418 R419 R461 R465
07-10221-10 Carbon Film Resistor 220R
,
1/4W
,
5% R432
07-10331-10 Carbon Film Resistor 330R
,
1/4W
,
5% R51
07-10391-10 Carbon Film Resistor 390R
,
1/4W
,
5% R138 R238
07-10471-10 Carbon Film Resistor 470R,1/4W,5%
R11 R21 R31 R32 R33 R34
R35 R36 R37 R38 R39
R139 R239 R310 R311
R312 R313 R314 R315
R316 R317 R318 R52 R503
07-10681-10 Carbon Film Resistor 680R,1/4W,5%
R41 R42 R43 R44 R47 R48
R49 R410 R411 R413
07-10911-10 Carbon Film Resistor 910R
,
1/4W
,
5% R426
07-10102-10 Carbon Film Resistor 1K,1/4W,5%
R147 R247 R474 R476
R458 R459 R460 R462
07-10132-10 Carbon Film Resistor 1.3K
,
1/4W
,
5% R422 R423 R424 R425
07-10222-10 Carbon Film Resistor 2K2,1/4W,5%
R58 R59 R428 R511 R512
R434 R526 R527 R440
R501
07-10472-10 Carbon Film Resistor 4K7,1/4W,5%
R401 R482 R466 R528
R541 R542 R543 R544
R545 R546 R547 R548
R549 R550 R551 R552
R553 R554 R333 R334
07-10512-10 Carbon Film Resistor 5K1
,
1/4W
,
5% R429 R533
07-10622-10 Carbon Film Resistor 6K2
,
1/4W
,
5% R480
07-10682-10 Carbon Film Resistor 6K8
,
1/4W
,
5% R12/1
07-10103-10 Carbon Film Resistor 10K,1/4W,5%
R470 R471 R502 R529
R556 R557 R558 R53 R54
R469 R508
07-10153-10 Carbon Film Resistor 15K
,
1/4W
,
5% R148 R248 R441 R530
07-10363-10 Carbon Film Resistor 36K
,
1/4W
,
5% R420 R421
07-10223-10 Carbon Film Resistor 22K,1/4W,5%
R12/2 R15 R25 R152 R252
R468 R444 R463 R464
07-10393-10 Carbon Film Resistor 39K,1/4W,5%
R19 R101 R105 R110 R29
R205 R210 R487 R488
R201
07-10473-10 Carbon Film Resistor 47K,1/4W,5%
R123 R223 R473 R477
R437
07-10563-10 Carbon Film Resistor 56K
,
1/4W
,
5% R436 R442 R445 R446
07-10104-10 Carbon Film Resistor 100K,1/4W,5%
R121 R122 R221 R222
R347 R348 R435 R448
R478 R479 R489 R490
R491
