NAD C 521BEE Service Manual

- 27 -
D301,D303,D306,D409,D411 4804-1480-2 DIODE 1N4148 AT
D302,D513 4805-3930-2 DIODE 1N5393 200V 1.5A
D403 4837-3V36-2 DZ 1/2W +-5% 3.3V TEMIC
D505 4840-1140-0 ZD 1.3W 3.3V 5% AT
TRANSISTOR
Q101,Q104,Q105,Q312,Q313 4860-0060-5 TR SS8550 C/D SAMSUNG RL
Q103,Q106,Q107,Q307-Q309,Q520 4860-0050-5 TR SS8050 C/D SAMSUNG RL
Q301-Q304 4860-1780-5 TR 2SD655F HFE:600-1200
Q305,Q405 485C-114E-5 TR DTC114ES
Q401,Q403 4860-0660-5 TR 2SA1015 (G.R.) RL
Q402 4851-012F-5 TR 2SD1012F/G HFE
Q404 485A-114E-5 TR DTA114ESA ROHM
HEATSINK
U501,U503,U506,U507 5400-9130-0 HEAT SINK FOR 7805 2438-
U502 5400-0831-0 HEATSINK
WIRE
M101 7012-6536-0 CONN WIRE ASSY 5PIN P2.0
M102C 7012-6232-0 WIRE CON 16P P=1.0
M105 7012-6538-0 CONN WIRE ASSY 6PIN P2.0
PC BOARD
1725-221A-0102 PCB MAIN N0A10C C521I
MISCELLANEOUS
2601-2608-0601 FIBRE WASHER M2.6 0.8T
C-GND1,M320 4132-1061-0 SOLDER TAG
M303 2704-0060-0 EMC FILTER
M502-M505 4131-9131-0 FUSE HOLDER 6.5MM PITCH
PWR
ASSY
PC BOARD
*AH PCB-N0A60C-PWR PCB ASSY PWR N0A60C
*CE PCB-N0A61C-PWR PCB ASSY PWR N0A61C
TRANSFORMER
M500 1806-2194-0 EI-57 TRANSFORMER 740
WIRE
M500A 7707-1130-2004 CONN WIRE ASSY 7P P2.5
PC BOARD
1723-006A-0000 PCB-TRANSFORMER A0140C
MISCELLANEOUS
J406,J407 4132-1071-0 TERMINAL PIN
Reference No. Part No. Description
NOTE: - The components identified by
mark are critical for risk of fire and electrical shock.
Replace only with part number specified.
- <*AH > : USA, Canadian model only.
- <*C > : European model only.
- Capacitors : CP-Polystyrene, CM-Mylar, CE-Electrolytic, CC-Ceramic, CTC-NPO.
- Resistors : RMF-Metal Film, RCF-Carbon Film, RWR-Wirewound Metal Oxide.
