NAD C 521BEE Service Manual

- 23 -
DISP ASSY
PC BOARD
PCB-N0A60C-DISP PCB ASSY DISP N0A60C
WIRE
M505A,M505B 7009-9630-0 CONN WIRE ASSY 14P 100MM
M509A 7010-1300-1 CN ASSY SHIELD 2P P2.5
PC BOARD
1725-221A-0102 PCB MAIN N0A10C C521I
MISCELLANEOUS
0011 4134-3011-0 LCD/EL HOLDER
0015 3716-3505-0 PC SHEET FILTER
0016 3716-3502-0 POLYESTER SHEET LEE
0017 4134-3041-0 LCD CORNER BRACKET
M113 4816-043T-3 IR SENSOR PIC-26043TM2
M501 2460-1340-2 LCD DISPLAY NEGATIVE
M502 2450-1146-0 EL BACKLIGHT
KEY
ASSY
PC BOARD
PCB-N0A60C-KEY PCB ASSY KEY N0A60C
RESISTOR
R301,R306,R307 4711-102A-2 RMF 1/8W 1K 1% AT
R302,R303 4711-622A-2 RMF 1/8W 6.2K 1% AT
R304,R305 4711-202A-2 RMF 1/8W 2K 1% AT
SWITCH
M101-M110 5200-3538-0 SWITCH, TACT SKHHBY 7MM
WIRE
M120C 7012-6347-0 CONNECTOR WIRE ASSY
PC BOARD
1725-211B-0000 PCB KEY N0A60C
LED
ASSY
PC BOARD
PCB-N0A60C-LED PCB ASSY LED N0A60C
LED
D304 3700-3517-RG LED RED/GREEN (L-469HGW)
WIRE
M301B 7703-1280-2004 CONN.ASSY 3P P2.5 L=280
PC BOARD
1725-221A-0102 PCB MAIN N0A10C C521I
ELECTRICAL PARTS LIST
Reference No. Part No. Description

NAD C 521BEE Specifications

General

Brand	NAD
Model	C 521BEE
Category	CD Player
Language	English
