- 24 -
LIVE ASSY
PC BOARD
*AH PCB-N0A60C-LIVE PCB ASSY LIVE N0A60C
*CE PCB-N0A61C-LIVE PCB ASSY LIVE N0A61C
SWITCH
M802 5200-3151-0-01 POWER SWITCH
PC BOARD
1725-221A-0102 PCB MAIN N0A10C C521I
MISCELLANEOUS
C800 8910-0049-0 CAP400V 4700P
M801,M803,M806 4132-1071-0 TERMINAL PIN
M804 *CE 4132-1071-0 TERMINAL PIN
M805 *AH 4132-1071-0 TERMINAL PIN
M810 *CE 1806-2170-0 EMI FILTER TLN12UA
MAIN
ASSY
PC BOARD
PCB-N0A60C-MAIN PCB ASSY MAIN N0A60C
CAPACITOR
C101-C103,C207,C208,C210, 150F-104K-2-FC CC 50V 0.1µF 10% AT 3.5x2
C213,C217,C222,C227,C228,
C304,C386,C521
C105-C110,C230,C522 157D-107M-5-IU CE 16V 100µF 20% RL 5x11
C111 157F-225M-5-IUNK CE 50V 2.2µF 20% RL 5X11
C201,C202,C204,C205 150F-221K-2-FC CC 50V 220pF 10% AT 3.5x2
C203,C216,C221,C303,C387 150F-103K-2-FC CC 50V 0.01µF 10% AT 3.5x2
C206,C352,C353 150F-331K-5-GE CC 50V 330pF 10% RL 4x3
C209,C223 153F-152J-5-JM CM 50V 1500PF 5% RL 5.8x7
C211,C212 15CH-270J-5-GG CTC 0/60 27pF 5% RL 4x4
C214,C215 150F-471K-2-FC CC 50V 470pF 10% AT 3.5x2
C218 150F-101K-2-FC CC 50V 100pF 10% AT 3.5x2
C219,C220 150F-474M-5-II CC 50V 0.47µF 20% RL 5X5
C226 157F-334K-5-IU CE 50V 0.33µF 10% RL 5x11
C301,C302 15CH-330J-5-IG CTC 0/60 33pF 5% RL 5x4
C305 157D-227M-5-OMK CE 16V 220µF 20% RL 8x7
C307,C309 157C-476M-5-IU CE 10V 47µF 20% RL 5x11
C308,C320,C321,C323-C325, 157B-106M-5-EI CE 6.3V 10µF 20% RL 3x5
C332,C334
C310,C508,C525 157C-108M-5-S5 CE 10V 1000µF 20% RL 10x16
C322,C326,C327,C380,C381, 157B-106M-5-EI CE 6.3V 10µF 20% RL 3x5
C417,C501-C526,C528,C531,
C532,C534,C535,C537,C540-C543
C328,C329 15CH-200J-5-GG CTC 0/60 20pF 5% RL 4x4
C330 153F-103J-5-IM CM 50V 0.01µF 5% RL 5X7
C362,C363 153F-472J-5-KM CM 50V 4700pF 5% RL 6x7
C366,C367 158F-681J-5-KW CP 50V 680pF 5% RL 6x12
C368,C369,C375,C376 157E-226K-5-IU CE 25V 22µF 10% RL 5x11
C377-C379,C382 153F-224J-5-MIB CM 50V 0.22µF 5% RL 7x5
C383 157C-226M-5-IU CE 10V 22µF 20% RL 5x11
C384 150F-102K-2-FC CC 50V 1000pF 10% AT 3.5x2
Reference No. Part No. Description
To Next Page
