NAD C 521BEE Service Manual

- 25 -
C385 150F-222K-2-GD CC 50V 0.0022µF 10% AT
C407 157D-228M-5-X9E CE 16V 2200µF 20% RL 12.5x20
C418,C530 157E-106M-5-IU CE 25V 10µF 20% RL 5x11
C506,C507 157E-228M-5-X9 CE 25V 2200µF 20% RL 12.5x20
C511 157C-227M-5-KW CE 10V 220µF 20% RL 6x12
C512,C513 157D-108M-5-S9 CE 16V 1000µF 20% RL 10x20
C518 157E-107M-5-KW CE 25V 100µF 20% RL 6x12
C523 157F-225M-5-IU CE 50V 2.2µF 20% RL 5x11
C524 153F-223K-5-LQ CM 50V 0.022µF 10% RL 6.5x9
C527 157C-477M-5-OW CE 10V 470µF 20% RL 8x12
C529 157D-338M-5-W@ CE 16V 3300µF 20% RL 12x26
C533 157D-477M-5-OY CE 470µF +-20% RL 8X13
C536,C537 153F-272J-5-JM CM 50V 2700PF 5% RL 5.8x7
C710 157B-107M-5-KM CE 6.3V 100µF 20% RL 6x7
COIL
L101,L102,L302 1801-100K-M COIL 10µH 10% BL7.0
L201 1801-270K-M COIL 27 µH,10%,AL,BL7
L301 1802-0450-0 DIGITAL COIL
TRANSFORMER
M501 1806-2320-0 TRANSFORMER STEP-UP 5V
WAFER/CONNECTOR
M102 2101-1382-0 CONNECTOR FLEXIBLE 16P
M120 2102-051S-004 5P ST.WAFER
M301A 2102-031S-004 3 PIN ST. WAFER
M500A 2102-071S-004 WF T8 DE 7PIN COULOMB
M505A,M505B 2102-141S-004 14P ST. WAFER P=2.5
M509 2102-021S-004 2P ST.WAFER
M509A 2102-022S-008 WAFER 2PIN PITCH=2.54MM
JACK
M318 2113-1170-0 1P RCA JACK YL AU
M317 2113-1300-0 2P RCA JACK W/R AU
CRYSTAL
M302 2300-0110-0 CRYSTAL 16.9344 MHZ
X301 2300-1420-0 CRYSTAL 8MHZ
SCREW
2954-2608-3000 SCREW BT 2.6X8 BLACK
2954-3008-0000 TAPPING 3X8MM B-TITE
IC
U101 3131-8030-0 IC CXA2581N ASP FOR CD S
U201 3131-8040-0 IC BA6392FP 4-CHANNEL
U301 3131-8000-0 IC CXD3017Q DSP FOR CD
U302 3130-5660-0 IC PCM1710U D/A
U305,U306 3130-2430-0 IC-NE5532 OPER. AMP PHIL
U401 3131-8020-1 IC M38223M4 MICRO MASK
U403 3130-4160-0 IC TC74HC00AP DIGITAL
U501,U506 3130-2020-3 IC 7805 REG 5V 1.5A
U502 3130-2520-2 IC 7812H 12V REG, T0220F
U503 3130-3800-0 IC UPC79M12HF REGULATOR
U504 3130-9030-0 IC NJM78L09A 9V 0.1A
