NAD C 521i User Manual

28
POWER SWITCH
M802 5200-3151-0-01 POWER SWITCH
TRANSFORMER
M810 *C 1806-2170-0 EMI FILTER TLN12UA 150W3R0
TRANSFORMER
ASSEMBLY
4000 *AH PCB-N0A10C-PWR TRANSFORMER ASSEMBLY
4000 *C PCB-N0A11C-PWR TRANSFORMER ASSEMBLY
TRANSFORMER
M500 1806-2194-0 EI-57 TRANSFORMER 740 AC3
FUSE
ASSEMBLY
FUSES
M502-M504 *AH 5120-0020-0 FU T1A 250V UL/CSA 5x20MM
M502-M504 *C 5120-0018-0 FU T1A 250V SEMKO/UDE 5x20MM
M505 *AH 5120-0052-0 FUSE T1.6A 250V 5x20MM UL/CSA
M505 *C 5120-0050-0 FUSE T1.6A 250V 5x20MM SEMKO/VDE
MAIN BOARD
PCB BOARD
5000 * PCB-N0A10C-MAIN MAIN ASSEMBLY
CAPACITORS
C101-C103 150F-104K-2-FC CC 50V 0.1µF 10% AT 3.5x2
C105-C110 157D-107M-5-IU CE 16V 100µF 20% RL 5x11
C111 157F-225M-5-IUNK CE 50V 2.2µF 20% 5x11 NP
C201,C202,C204,C205 150F-221K-2-FC CC 50V 220pF 10% AT 3.5x2
C203,C216,C221 150F-103K-2-FC CC 50V 0.01µF 10% AT 3.5x2
C206 150F-331K-5-GE CC 50V 330pF 10% RL 4x3
C207,C208 150F-104K-2-FC CC 50V 0.1µF 10% AT 3.5x2
C209,C223 153F-152J-5-JM CM 50V 1500PF 5% RL 5.8x7
C210,C213,C217,C222 150F-104K-2-FC CC 50V 0.1µF 10% AT 3.5x2
C211,C212 15CH-270J-5-GG CTC 0/60 27pF 5% RL 4x4
C214,C215 150F-471K-2-FC CC 50V 470pF 10% AT 3.5x2
C218 150F-101K-2-FC CC 50V 100pF 10% AT 3.5x2
C219,C220 150F-474M-5-II CC 50V 0.47µF 20% RL 5X5
C226 157F-334K-5-IU CE 50V 0.33µF 10% RL 5x11
C227,C228 150F-104K-2-FC CC 50V 0.1µF 10% AT 3.5x2
C229 157D-477M-5-OY CE 470µF +-20% RL 8X13
C230 157D-107M-5-IU CE 16V 100µF 20% RL 5x11
C301,C302 15CH-330J-5-IG CTC 0/60 33pF 5% RL 5x4
C303,C387 150F-103K-2-FC CC 50V 0.01µF 10% AT 3.5x2
C304,C386 150F-104K-2-FC CC 50V 0.1µF 10% AT 3.5x2
C305 157D-227M-5-OMK CE 16V 220µF 20% RL 8x7
C307,C309 157C-476M-5-IU CE 10V 47µF 20% RL 5x11
C308 157B-106M-5-EI CE 6.3V 10µF 20% RL 3x5
C310 157C-108M-5-S5 CE 10V 1000µF 20% RL 10x16
C320,C321, 157B-106M-5-EI CE 6.3V 10µF 20% RL 3x5
C322,C326,C327,C380,C381 150F-104K-5-II CC 50V 0.1µF 10% RL 5x5
C323-C325,C332,C334 157B-106M-5-EI CE 6.3V 10µF 20% RL 3x5
C328,C329 15CH-200J-5-GG CTC 0/60 20pF 5% RL 4x4
Reference No. Part No. Description
