NAD C 521i User Manual

31
R311,R331,R335,R347 4701-102J-C RCF 1/8W 1K 5% ATS
R312-R314 4701-223J-C RCF 1/8W 22K 5% ATS
R317 4711-362A-2 RMF 1/8W 3.6K 1% AT
R318,R330,R338,R346 4701-103J-C RCF 1/8W 10K 5% ATS
R320 4701-471J-C RCF 1/8W 470R 5% ATS
R321-R323 4701-472J-C RCF 1/8W 4.7K 5% ATS
R325-R329,R377,R378 4701-472J-C RCF 1/8W 4.7K 5% ATS
R334,R341 4701-561J-C RCF 1/8W 560R 5% ATS
R339,R373,R374 4701-104J-C RCF 1/8W 100K 5% ATS
R340 4701-100J-C RCF 1/8W 10R 5% ATS
R354,R357 4701-271J-C RCF 1/8W 270R 5% ATS
R355,R356 4711-332A-2 RMF 1/8W 3.3K 1% AT
R359,R360 4701-682J-C RCF 1/8W 6.8K 5% ATS
R363,R364 4701-152J-C RCF 1/8W 1.5K 5% ATS
R367,R368,371,R372 4701-222J-C RCF 1/8W 2.2K 5% ATS
R375,R376,R379,R380,R383,R521 4701-151J-C RCF 1/8W 150R 5% ATS
R381,R382 4701-472J-C RCF 1/8W 4.7K 5% ATS
R384 4701-750J-C RCF 1/8W 75R 5% ATS
R390-R393 4717-221J-C RMF 1/2W 220R 5% ATS
R403 4701-103J-C RCF 1/8W 10K 5% ATS
R405 4701-223J-C RCF 1/8W 22K 5% ATS
R406,R415 4701-752J-C RCF 1/8W 7.5K 5% ATS
R412 4701-472J-C RCF 1/8W 4.7K 5% ATS
R413,R416 4701-473J-C RCF 1/8W 47K 5% ATS
R414 4701-104J-C RCF 1/8W 100K 5% ATS
R501 4711-273A-C RMF 1/8W 27K 1% ATS
R502 4701-183J-C RCF 1/8W 18K 5% ATS
R520 4701-513J-C RCF 1/8W 51K 5% ATS
ICS
U101 3131-8030-0 IC CXA2581N ASP FOR CD
U201 3131-8040-0 IC BA6392FP 4-CHANNEL BTL
U301 3131-8000-0 IC CXD3017Q DSP FOR CD
U302 3130-5660-0 IC PCM1710U D/A CONVERTER
U305,U306 3130-2430-0 IC-NE5532 OPER. AMP PHILIP
U401 3131-8020-0 IC M38223E4HP4 MICRO OTP
3131-8020-1 IC M38223E4HP4 MICRO MASK
U403 3130-4160-0 IC TC74HC00AP DIGITAL
U501,U506 3130-2020-3 IC 7805 REG 5V 1.5A
U502 3130-2520-3 IC 7812 12V REGULATOR
U503 3130-3800-0 IC UPC79M12HF REGULATOR
U504 3130-9030-0 IC NJM78L09A 9V 0.1A
U507 3130-2790-1 IC NJM7808FA +8V REG
Reference No. Part No. Description
NOTE: - The components identified by
mark are critical for risk of fire and electrical shock.
Replace only with part number specified.
- <*AH > : USA, Canadian model only.
- <*C > : European model only.
- Capacitors : CP-Polystyrene, CM-Mylar, CE-Electrolytic, CC-Ceramic, CTC-NPO.
- Resistors : RMF-Metal Film, RCF-Carbon Film, RWR-Wirewound Metal Oxide.
