NAD C516BEE - Page 38

3-2
Ref NO PART NUMBER Description REMARK
Switch PCB Ass'y CUP12490Z-2 : C516BEEAH, C516BEEC, C516BEECT
S307 CST1A012ZT SW , TACT
D302 CVD50BOBBWGA L.E.D , 2 COLOR (ORG , BLUE)
BN41 CWB1B905180EN WIRE ASS'Y
Trans PCB Ass'y CUP12490Z-3 : C516BEEC, C516BEECT
T801 CLT5I009ZE TRANS , SUB CD6002/N C516BEEC/CT
T802 CLT5M028ZES TRANS , POWER(EUR/UK) C516BEEC/CT
F801 KBA2C0315TLEY
FUSE(218Series, 250V/315mA)
C516BEEC/CT
RY81 CSL1E002ZE RELAY,G5PA-1,DC6V,1C1P
CN82 CJP02KA060ZY WAFER, 2P, 3.96mm
HF81 KJCFC5S HOLDER , FUSE
HF82 KJCFC5S HOLDER , FUSE
BN81 CWB1C913120EN WIRE ASS'Y(13P, 120mm)
C800 KCKDKS472ME CAP , CERAMIC(X1/Y2/SC)
Trans PCB Ass'y CUP12490Z-3 : C516BEEAH
T801 CLT5I009ZU TRANS , SUB C515 C516BEEAH
T802 CLT5M028ZUS TRANS , POWER C515 C516BEEAH
F801 KBA2C0630TLEY FUSE(218Series, 250V/630mA) C516BEEAH
RY81 CSL1E002ZE RELAY,G5PA-1,DC6V,1C1P
CN82 CJP02KA060ZY WAFER, 2P, 3.96mm
HF81 KJCFC5S HOLDER , FUSE
HF82 KJCFC5S HOLDER , FUSE
BN81 CWB1C913120EN WIRE ASS'Y(13P, 120mm)
C800 KCKDKS472ME CAP , CERAMIC(X1/Y2/SC)
Jack PCB Ass'y CUP12490Z-5 : C516BEEAH, C516BEEC, C516BEECT
BN91 CWB2B905080EN WIRE ASS'Y
JK91 CJJ4N067Z JACK , 2P
JK92 CJSJST1124 MODULE , OPTICAL(TX 16MHz)
JK93 CJJ4M045Z JACK , BOARD
CN92 CJP13GA115ZY WAFER, FFC(13P-1.25mm, STRAIGHT)
CN93 CJP07GB113ZY WAFER, FFC(5P-1mm, ANGLE)
