SECTION 3
ELECTRICAL PARTS LIST
3-1
[FRONT & POWER PCB Ass'y] COP12490B(C516BEEC, C516BEECT) , COP12490C(C516BEEAH)
CUP12489Z-1
Ref NO PART NUMBER Description REMARK
C301 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF)
C400 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF)
C401 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF)
C402 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF)
C404 CCUS1H470JA CAP, CHIP(1608, 50V/47pF)
C405 CCUS1H470JA CAP, CHIP(1608, 50V/47pF)
C406 CCUS1H470JA CAP, CHIP(1608, 50V/47pF)
C408 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF)
C409 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF)
C411 CCUS1H470JA CAP, CHIP(1608, 50V/47pF)
C412 CCUS1H470JA CAP, CHIP(1608, 50V/47pF)
C413 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF)
C414 CCUS1H104KC CAP, CHIP(1608, 50V/0.1uF)
D400 CVD1SS355T DIODE , CHIP , SWITCHING
D401 CVD1SS355T DIODE , CHIP , SWITCHING
D402 CVD1SS355T DIODE , CHIP , SWITCHING
D403 CVD1SS355T DIODE , CHIP , SWITCHING
D404 CVD1SS355T DIODE , CHIP , SWITCHING
D405 CVD1SS355T DIODE , CHIP , SWITCHING
D406 CVD1SS355T DIODE , CHIP , SWITCHING
D407 CVD1SS355T DIODE , CHIP , SWITCHING
L901 CLZ9R001Z FERRITE , CHIP BEAD(60ohm, 2012)
Q400 HVTKTC3875SYRTK T.R , CHIP , SOT-23
Q401 CVTRT1P144C T.R,RT1P144C(10K-47K)
Q402 CVTRT1N141C T.R,RT1N141C(10K-10K)
R400 CRJ10DJ182T RES, CHIP(1608/5%/1.8Kohm)
R401 CRJ10DJ121T RES, CHIP(1608/5%/120ohm)
R402 CRJ10DJ680T RES, CHIP(1608/5%/68ohm)
R403 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm)
R404 CRJ10DJ102T RES, CHIP(1608/5%/1Kohm)
R405 CRJ10DJ152T RES, CHIP(1608/5%/1.5Kohm)
R406 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm)
R407 CRJ10DJ102T RES, CHIP(1608/5%/1Kohm)
R408 CRJ10DJ152T RES, CHIP(1608/5%/1.5Kohm)
R409 CRJ10DJ221T RES, CHIP(1608/5%/220ohm)
R410 CRJ10DJ221T RES, CHIP(1608/5%/220ohm)
R411 CRJ10DJ221T RES, CHIP(1608/5%/220ohm)
R412 CRJ10DJ102T RES, CHIP(1608/5%/1Kohm)
R413 CRJ10DJ103T RES, CHIP(1608/5%/10Kohm)
R414 CRJ10DJ472T RES, CHIP(1608/5%/4.7Kohm)
R415 CRJ10DJ332T RES, CHIP(1608/5%/3.3Kohm)
C320 CCEA1HKS100T CAP, ELECT(50V/10uF)-S
C403 CCEA1CKS101T CAP, ELECT(16V/100uF)-S
C407 CCEA1HKS1R0T CAP, ELECT(50V/1uF)-S
C410 CCEA1HKS100T CAP, ELECT(50V/10uF)-S
S301 CST1A012ZT SW , TACT
S302 CST1A012ZT SW , TACT
S303 CST1A012ZT SW , TACT
S304 CST1A012ZT SW , TACT
S305 CST1A012ZT SW , TACT
S306 CST1A012ZT SW , TACT
BK10 CMD1A807 BRACKET , FIP
BK11 CMD1A807 BRACKET , FIP
CN41 CJP05GA19ZY WAFER , STRAIGHT
CN42 CJP17GB116ZY WAFER, FFC(17P-1.25mm, ANGEL)
FL41 CFLCIG201411 VFD , ZBOE , CIG20-1411 , CIG-TYPE
RS01 CRVKSM603TH5B SENSOR , REMOTE/U
CWC4C4A13B100B10
CABLE , CARD (13P,1.25MM,100MM,B,10MM)
CWC4C4A17B100B10 CABLE , CARD (17P,1.25MM100MM,,B,10MM)
C4FJ104 TAPE , BOTH SID
