NAD C545BEE - REFERENCE; NOTES ON DISCS; GENERAL PARAMETERS; DIMENSION AND WEIGHT

HANDLING DISCS
Do not touch the playback side of the disc. Hold the disc by the edges so that
ngerprints do not get on the surface. Never stick paper or tape on the disc.
STORING DISCS
After playing, store the disc in its case. Do not expose the disc to direct
sunlight or sources of heat and never leave it in a parked car exposed to
direct sunlight.
CLEANING DISCS
Fingerprints and dust on the disc can cause poor picture quality and sound
distortion. Before playing, clean the disc with a clean cloth. Wipe the disc
from the center out.
Do not use strong solvents such as alcohol, benzine, thinner, commercially
available cleaners, or anti-static spray intended for older vinyl records
REFERENCE
NOTES ON DISCS
SPECIFICATIONS
GENERAL PARAMETERS
Output level - Analog 2.2 ± 0.1 V
Optical -22.5 ± 3.5 dBm
Coaxial 650 ± 150 mV
Frequency response ± 0.3 dB (ref. 0 dB 20 Hz-1 kHz)
± 0.5 dB (ref. 0 dB 5 kHz-20 kHz)
Total harmonic distortion < 0.01% (ref. 1 kHz)
Signal/Noise ratio 118 dB (A-weighted, ref. 1 kHz)
Channel balance ± 0.5 dB (ref. 0dB 1kHz)
Dynamic range 95 dB
Channel separation > 90 dB
De-emphasis -3.73 to -5.33 dB (ref. 0dB 5 kHz)
-8.04 to -10.04 dB (ref. 0 dB 16 kHz)
Linearity ± 0.01 dB (ref. 1 kHz at -3 dB)
± 0.02 dB (ref. 1 kHz at -6 dB)
± 0.02 dB (ref. 1 kHz at -10 dB)
± 0.05 dB (ref. 1 kHz at -20 dB)
± 0.15 dB (ref. 1 kHz at -60 dB)
DIMENSION AND WEIGHT
Unit Dimensions (W x H x D) 435 x 285 x 70 mm (Net)
435 x 293 x 86 mm (Gross)*
Net weight 4.9 kg
Shipping weight 6.3 kg
* - Gross dimensions include feet, extended buttons and rear panel terminals.
Specications are subject to change without notice. For updated documentation and features, please log onto www.NADelectronics.com for the latest
information about C 545BEE.
